CF-R900 Compact Flash GPS Receiver
EverMore Technology, Inc.
2F, No.7, R&D Road 1, Science-Based Industrial Park, Hsinchu, Taiwan, 300, R.O.C.
http://www.emt.com.tw
Page 2
Specification:
Features Description
General L1 1575.42MHz, C/A code, 20-channel all in view
tracking
Sensitivity -159 dBm (typical)
Update Rate 1 Hz
Accuracy Position: <15m(95%) without S/A
Velocity: 0.1 m/sec without S/A
Time:
± 100ns synchronized to GPS time
Acquisition Cold start: 42 sec average
Warm start: 38 sec average
Hot start : 1 sec average
Dynamics Altitude : 18,000m Max
Velocity: 83m/s
Acceleration: 4g Max
Reacquisition Time 0.1 second
Datum WGS-84
Protocol NMEA-0183 V2.2 , Baud rate: 4800 , 8-None-1
NMEA Message Default : GGA, GSA, GSV, RMC
Primary Power VCC1 : 3.3VDC ±0.1Vp-pripple
VCC2 : 5VDC ± 0.5Vp-p ripple
DC Current 85 mA
Operation Temperature -10
o
C to +70
o
C
Storg Temperature -40
o
C to +80
o
C
Operating Humidity 5% to 90% non-condensing
Antenna Built-in Patch Antenna
Interface connector Compact Flash interface
Dimension/ Weight 71 mm x 47.5 mm x 25.4.mm / 67.5g
* Preliminary Specification, Subject To Change without Notice
