MAX15006/MAX15007
40V, Ultra-Low Quiescent-Current
Linear Regulators in 6-Pin TDFN/8-Pin SO
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
IN
= 14V, I
OUT
= 1mA, C
IN
= 0.1µF, C
OUT
= 2.2µF, T
A
= T
J
= -40°C to +125°C, unless otherwise noted. Typical specifications are
at T
A
= +25°C.) (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
IN to GND ...............................................................-0.3V to +45V
EN to GND..............................................................-0.3V to +45V
OUT to GND ...........................................................-0.3V to +12V
OUT Short-Circuit Duration ........................................Continuous
Maximum Current Into Any Pin (except IN and OUT) ......±50mA
Continuous Power Dissipation (T
A
= +70°C)
6-Pin TDFN-EP (derate 23.8mW/°C above +70°C) .......1904mW*
8-Pin SO-EP (derate 23.3mW/°C above +70°C) .........1860mW*
Thermal Resistance
θ
JA
, 6-Pin TDFN ...........................................................42°C/W
θ
JC
, 6-Pin TDFN ..........................................................8.5°C/W
θ
JA
, 8-Pin SO-EP ..........................................................43°C/W
θ
JC
, 8-Pin SO-EP ............................................................7°C/W
Operating Temperature Range .........................-40°C to +125°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Input Voltage Range
V
IN
4
40
V
I
OUT
= 0 (MAX15006)
10
17
I
OUT
= 0 (MAX15007)
11
18
I
OUT
= 100µA (MAX15006)
10.5
18
I
OUT
= 100µA (MAX15007)
11.5
19
I
OUT
= 1mA (MAX15006)
12
20
I
OUT
= 1mA (MAX15007)
13
21
I
OUT
= 50mA (MAX15006)
90
150
Ground Current
I
GND
Regulator on,
measured at GND
I
OUT
= 50mA (MAX15007)
93
150
µA
Shutdown Supply Current
I
SHDN
Regulator off (MAX15007 only)
3
5
µA
REGULATOR
Guaranteed Output Current
I
OUT
V
IN
≥ V
OUT
+
ΔV
DO
50
mA
MAX15006A/MAX15007A
3.25
3.3
3.35
Output Voltage
V
OUT
I
OUT
= 1mA (Note 2)
MAX15006B/MAX15007B
4.925
5.0
5.075
V
I
OUT
= 5mA, MAX15006B/MAX15007B
30
53
I
OUT
= 50mA, MAX15006B/MAX15007B
300
525
Dropout Voltage (Notes 3, 4)
ΔV
DO
I
OUT
= 50mA, MAX15006A/MAX15007A
700
mV
Line Regulation
6V
≤ V
IN
≤ 35V, I
OUT
= 1mA
0.25
%
Load Regulation
V
IN
= V
OUT
+ 3V, I
OUT
= 100µA to 50mA
0.7
1.5
%
*As per JEDEC51 Standard (Multilayer Board).
