MAX5480
8-Bit Parallel DAC in
QSOP-16 Package
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V DD = +5V, V REF = +10V, V OUT1 = V OUT2 = 0V, Circuit of Figure 1, T A = T MIN to T MAX , unless otherwise noted.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V DD to GND ............................................................-0.3V to +17V
REF to GND .........................................................................±25V
RFB to GND .........................................................................±25V
Digital Inputs to GND .................................-0.3V to (V
DD + 0.3V)
OUT1, OUT2 to GND................................................-0.3V to V DD
Operating Temperature Ranges
MAX5480_CEE....................................................0°C to +70°C
MAX5480_EEE .................................................-40°C to +85°C
Storage Temperature Range .............................-65°C to +160°C
Continuous Power Dissipation (T
A = +70°C)
MAX5480_ _EE (derate 8.3mW/°C above +70°C) ........667mW
Lead Temperature (soldering 10sec) ..............................+300°C
pin 15 to GND
All grades guaranteed monotonic over temperature
T A = T MIN to T MAX
CONDITIONS
400
LSB ±1/2 INL Relative Accuracy
Bits 8 Resolution
k Ω 5 10 20 R REF Input Resistance
%FSR/%
0.01 0.16
0.002 0.08
LSB ±1 DNL Differential Nonlinearity
LSB ±1 Gain Error (Note 1)
ppm/°C ±2
Gain Temperature
Coefficient (Note 2)
UNITS MIN TYP MAX SYMBOL PARAMETER
T A = +25°C
T A = T MIN to T MAX
V REF = ±10V
DAC code = full scale T A = T MIN to T MAX
nA
±400
Output Leakage Current
(I
OUT1 )
±50 T A = +25°C
V REF = ±10V
DAC code = zero scale T A = T MIN to T MAX
nA
±400
Output Leakage Current
(I
OUT2 )
±50 T A = +25°C
D0–D7 = 0V to
V
DD or V DD to 0V,
WR = CS = 0V,
OUT1 load =
100
Ω || 13pF
500
Output Current Settling Time
to 1/2LSB
MAX5480A
(Note 3)
T A = T MIN to T MAX
MAX5480B
0.01
PSR Supply Rejection
0.002 T A = +25°C
ns
250
T A = T MIN to T MAX
T A = +25°C
T A = +25°C
MAX5480A
(Note 3)
MAX5480B
MAX5480A
(Note 3)
MAX5480B
T A = T MIN to T MAX ns
T A = +25°C
T A = +25°C
V REF = ±10V,
100kHz sine
wave,
WR = CS = 0V
0.5
AC Feedthrough
(OUT1 or OUT2)
0.1
0.25
D0–D7 = V DD , WR = CS = 0V
D0–D7 = 0V, WR = CS = 0V
120
30
pF C OUT1 OUT1 Capacitance (Note 3)
D0–D7 = V DD , WR = CS = 0V
D0–D7 = 0V, WR = CS = 0V
30
120
pF C OUT2 OUT2 Capacitance (Note 3)
DC ACCURACY
REFERENCE INPUT
DYNAMIC PERFORMANCE
ANALOG OUTPUTS
