Figure 11. Shutdown Output Voltage
MAX4322/MAX4323/MAX4326/MAX4327/MAX4329
Single/Dual/Quad, Low-Cost, SOT23,
Low-Power, Rail-to-Rail I/O Op Amps
______________________________________________________________________________________ 11
R S
C L
MAX4322/MAX4323
MAX4326/MAX4327
MAX4329
Figure 7. Capacitive-Load-Driving Circuit
V
OUT
0V TO 2.7V
STEP FOR
POWER-UP
TEST
SUPPLY-CURRENT
MONITORING POINT
V
CC
10 Ω 2k
10k
2k
MAX4322/MAX4323
MAX4326/MAX4327
MAX4329
Figure 8. Power-Up Test Circuit
Figure 10. Power-Up Supply Current
V CC
TIME (5 µs/div)
VOLTAGE (1V/div)
OUT
Figure 9. Power-Up Output Voltage
V CC
(1V/div)
TIME (5 µs/div)
I CC
(500 µA/div)
SHDN
(1V/div)
TIME (2 µs/div)
OUT
(0.5V/div)
V CC = 2.7V
R L = 10k Ω
SHDN
(1V/div)
TIME (2 µs/div)
I CC
(500 µA/div)
V CC = 2.7V
Figure 12. Shutdown Enable/Disable Supply Current
