MAX16016/MAX16020/MAX16021
Low-Power µP Supervisory Circuits with
Battery-Backup Circuit and Chip-Enable Gating
20
______________________________________________________________________________________
Package Information
For the latest package outline information, go to
www.maxim-ic.com/packages
.
Selector Guide
PART
ALL LOGIC
OUTPUTS (EXCEPT
BATT_TEST)
MR
POWER-FAIL
COMPARATOR
WATCHDOG
TIMER
BATTON
LOW-
LINE
OUTPUT
BATTOK/
BATT_TEST/
RESET
CHIP-
ENABLE
MAX16016LTB_
Push-pull
√
√
WDI
√
—
—
—
MAX16016PTB_
Open-drain
√
√
WDI
√
—
—
—
MAX16020LTE_
Push-pull
√
√
WDI/WDO
√
√
BATTOK/
BATT_TEST
√
MAX16020PTE_
Open-drain
√
√
WDI/WDO
√
√
BATTOK/
BATT_TEST
√
MAX16021LTE_
Push-pull
√
√
WDI/WDO
√
√
BATTOK/
RESET
√
MAX16021PTE_
Open-drain
√
√
WDI/WDO
√
√
BATTOK/
RESET
√
Ordering Information (continued)
PART
TEMP RANGE
PIN-PACKAGE
MAX16020_TE_+T
-40°C to +85°C
16 TQFN-EP*
MAX16021_TE_+T
-40°C to +85°C
16 TQFN-EP*
PACKAGE TYPE
PACKAGE CODE
DOCUMENT NO.
10 TDFN
T1033-1
16 TQFN
T1644-4
The first placeholder “_” designates all output options. Letter
“L” indicates push-pull outputs and letter “P” indicates open-
drain outputs. The last placeholder “_” designates the reset
threshold (see Table 1).
T = Tape and reel.
+
Denotes a lead(Pb)-free/RoHS-compliant package.
*
EP = Exposed pad.
Chip Information
PROCESS: BiCMOS
