Page 4
MAX5550
Dual, 10-Bit, Programmable, 30mA
High-Output-Current DAC
4
_______________________________________________________________________________________
ELECTRICAL CHARACTERISTICS (continued)
(V
DD
= +2.7V to +5.25V, GND = 0, V
REFIN
= +1.25V, internal reference, R
FSADJ_
= 20k
Ω; compliance voltage = (V
DD
- 0.6V),
V
SCLK/SCL
= 0, T
A
= -40°C to +85°C, unless otherwise noted. Typical values are at V
DD
= +3.0V and T
A
= +25°C.) (Note 1)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Bus Free Time Between a STOP
and START Condition
t
BUF
1.3
µs
Setup Time for STOP Condition
t
SU:STO
160
ns
Maximum Capacitive Load for
Each Bus Line
C
B
400
pF
SPI TIMING CHARACTERISTICS (Figure 6)
SCLK Clock Period
t
CP
100
ns
SCLK Pulse-Width High
t
CH
40
ns
SCLK Pulse-Width Low
t
CL
40
ns
CS Fall to SCLK Rise Setup Time
t
CSS
25
ns
SCLK Rise to CS Rise Hold Time
t
CSH
50
ns
DIN Setup Time
t
DS
40
ns
DIN Hold Time
t
DH
0
ns
SCLK Fall to DOUT Transition
t
DO1
C
LOAD
= 30pF
40
ns
CS Fall to DOUT Enable
t
CSE
C
LOAD
= 30pF
40
ns
CS Rise to DOUT Disable
t
CSD
C
LOAD
= 30pF
40
ns
SCLK Rise to CS Fall Delay
t
CS0
50
ns
CS Rise to SCLK Rise Hold Time
t
CS1
40
ns
CS Pulse-Width High
t
CSW
100
ns
SPI TIMING CHARACTERISTICS FOR DAISY CHAINING (Figure 6)
SCLK Clock Period
t
CP
200
ns
SCLK Pulse-Width High
t
CH
80
ns
SCLK Pulse-Width Low
t
CL
80
ns
CS Fall to SCLK Rise Setup Time
t
CSS
25
ns
SCLK Rise to CS Rise Hold Time
t
CSH
50
ns
DIN Setup Time
t
DS
40
ns
DIN Hold Time
t
DH
0
ns
SCLK Fall to DOUT Transition
t
DO1
C
LOAD
= 30pF
40
ns
CS Fall to DOUT Enable
t
CSE
C
LOAD
= 30pF
40
ns
CS Rise to DOUT Disable
t
CSD
C
LOAD
= 30pF
40
ns
SCLK Rise to CS Fall Delay
t
CS0
50
ns
CS Rise to SCLK Rise Hold Time
t
CS1
40
ns
CS Pulse-Width High
t
CSW
100
ns
Note 1: 100% production tested at T
A
= +25°C. Limits over temperature are guaranteed by design.
Note 2: INL linearity is guaranteed from code 60 to code 1024.
Note 3: Connect a resistor from FSADJ_ to GND to adjust the full-scale current. See the Reference Architecture and Operation section.
Note 4: Settling time is measured from (0.25 x full scale) to (0.75 x full scale).
Note 5: The device draws higher supply current when the digital inputs are driven with voltages between (V
DD
- 0.5V) and (GND +
0.5V). See the Supply Current vs. Digital Input Voltage graph in the Typical Operating Characteristics.
