command byte) that occurs immediately after POR
returns the current local temperature data.

Single-Shot

The single-shot command immediately forces a new
conversion cycle to begin. If the single-shot command
is received while the MAX6642 is in standby mode
(RUN bit = 1), a new conversion begins, after which the
device returns to standby mode. If a single-shot con-
version is in progress when a single-shot command is
received, the command is ignored. If a single-shot
command is received in autonomous mode (RUN bit =
0), the command is ignored.

Configuration Byte Functions

The configuration byte register (Table 4) is a read-write
register with several functions. Bit 7 is used to mask
(disable) interrupts. Bit 6 puts the MAX6642 into stand-
by mode (STOP) or autonomous (RUN) mode. Bit 5 dis-
ables local temperature conversions for faster (8Hz)
remote temperature monitoring. Bit 4 prevents setting
the ALERT output until two consecutive measurements
result in fault conditions.

Status Byte Functions

The status byte register (Table 5) indicates which (if
any) temperature thresholds have been exceeded. This
byte also indicates whether the ADC is converting and
whether there is an open-circuit fault detected on the
external sense junction. After POR, the normal state of
all flag bits is zero, assuming no alarm conditions are
present. The status byte is cleared by any successful
read of the status byte after the overtemperature fault
condition no longer exists.

Slave Addresses

The MAX6642 has eight fixed addresses available.
These are shown in Table 6.

The MAX6642 also responds to the SMBus alert
response slave address (see the Alert Response
Address
section).

POR and UVLO

To prevent ambiguous power-supply conditions from
corrupting the data in memory and causing erratic
behavior, a POR voltage detector monitors V

CC

and

clears the memory if V

CC

falls below 2.1 (typ). When

power is first applied and V

CC

rises above 2.1 (typ),

the logic blocks begin operating, although reads and
writes at V

CC

levels below 3V are not recommended. A

second V

CC

comparator, the ADC undervoltage lockout

(UVLO) comparator prevents the ADC from converting
until there is sufficient headroom (V

CC

= +2.7V typ).

Power-Up Defaults

Power-up defaults include:

• ALERT output is cleared.

• ADC begins autoconverting at a 4Hz rate.

• Command byte is set to 00h to facilitate quick

local Receive Byte queries.

• Local (internal) T

HIGH

limit set to +70°C.

• Remote (external) T

HIGH

limit set to +120°C.

Applications Information

Remote-Diode Selection

The MAX6642 can directly measure the die temperature
of CPUs and other ICs that have on-board temperature-
sensing diodes (see the Typical Operating Circuit) or
they can measure the temperature of a discrete diode-
connected transistor.

Effect of Ideality Factor

The accuracy of the remote temperature measurements
depends on the ideality factor (n) of the remote “diode”
(actually a transistor). The MAX6642 is optimized for n
= 1.008, which is the typical value for the Intel Pentium
III. A thermal diode on the substrate of an IC is normally
a PNP with its collector grounded. DXP should be con-
nected to the anode (emitter) and the cathode should
be connected at GND of the MAX6642.

If a sense transistor with an ideality factor other than
1.008 is used, the output data is different from the data
obtained with the optimum ideality factor. Fortunately,
the difference is predictable.

Assume a remote-diode sensor designed for a nominal
ideality factor n

NOMINAL

is used to measure the tem-

perature of a diode with a different ideality factor n

1

.

The measured temperature T

M

can be corrected using:

T

T

n

n

M

ACTUAL

NOMINAL

=

1

MAX6642

±1°C, SMBus-Compatible Remote/Local

Temperature Sensor with Overtemperature Alarm

_______________________________________________________________________________________

9

PART NO. SUFFIX

ADDRESS

MAX6642ATT90

1001 000

MAX6642ATT92

1001 001

MAX6642ATT94

1001 010

MAX6642ATT96

1001 011

MAX6642ATT98

1001 100

MAX6642ATT9A

1001 101

MAX6642ATT9C

1001 110

MAX6642ATT9E

1001 111

Table 6. Slave Address
