Two-Lane and Four-Lane DisplayPort Passive
Switches with Separate AUX/HPD Control
MAX4998/MAX14998
Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are implied.
Maxim reserves the right to change the circuitry and specifications without notice at any time.
10
Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600
©
2009 Maxim Integrated Products
Maxim is a registered trademark of Maxim Integrated Products, Inc.
Applications Information
Board Layout
High-speed switches require proper layout and design
procedures for optimum performance. Keep design-
controlled impedance PCB traces as short as possible.
Ensure that power-supply bypass capacitors are placed
as close to the device as possible. Multiple bypass
capacitors are recommended. Connect all grounds and
the exposed pad to large ground planes.
Chip Information
PROCESS: CMOS
Package Information
For the latest package outline information and land patterns,
go
to
.
Note that a “+”, “#”, or
“-” in the package code indicates RoHS status only. Package
drawings may show a different suffix character, but the drawing
pertains to the package regardless of RoHS status.
PACKAGE TYPE
PACKAGE CODE
DOCUMENT NO.
28 TQFN-EP
T283555+1
42 TQFN-EP
T423590+1
