MAX9943/MAX9944
High-Voltage, Precision, Low-Power Op Amps
_______________________________________________________________________________________ 3
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
-13.5V ≤ V O ≤ +13.5V, R L = 10kΩ,
T A = +25°C
115 130
-13.5V ≤ V
O
≤ +13.5V, R
L
= 10kΩ,
T A = -40°C to +125°C
100
-12V ≤ V O ≤ +12V, R L = 600Ω,
T A = +25°C
100 110
Open-Loop Gain A VOL
-12V ≤ V O ≤ +12V, R L = 600Ω,
T A = -40°C to +85°C
90
dB
R L = 10kΩ
V CC -
0.2
T A = +25°C
V
CC
-
1.8
V OH
R L = 600Ω
T A = -40°C to +85°C V CC - 2
R L = 10kΩ
V EE +
0.1
T A = +25°C
V EE +
1
Output Voltage Swing
V OL
R
L
= 600Ω
T A = -40°C to +85°C
V
EE
+
1.1
V
T A = +25°C 60
Short-Circuit Current I SC
T
A
= -40°C to +125°C 100
mA
AC CHARACTERISTICS
Gain Bandwidth Product GBWP 2.4 MHz
Slew Rate SR -5V ≤ V OUT ≤ +5V 0.35 V/µs
Input Voltage Noise Density e n f = 1kHz 17.6 nV/√Hz
Input Voltage Noise TOTAL NOISE 0.1Hz ≤ f ≤ 10Hz 500 nV
Input Current Noise Density I n f = 1kHz 0.18 pA/√Hz
Capacitive Loading C LOAD No sustained oscillation 1000 pF
ELECTRICAL CHARACTERISTICS (continued)
(V CC = 15V, V EE = -15V, V CM = 0, R L = 10kΩ to GND, GND = 0, T A = -40°C to +125°C. Typical values are at T A = +25°C, unless oth-
erwise noted.) (Note 3)
Note 3: All devices are 100% production tested at T A = +25°C. Temperature limits are guaranteed by design.
