MAX4165–MAX4169
High-Output-Drive, Precision, Low-Power, Single-
Supply, Rail-to-Rail I/O Op Amps with Shutdown
______________________________________________________________________________________ 15
Typical Operating Circuit
___________________Chip Information
Ordering Information (continued)
V CC
R2
C2
C1
V IN
32 Ω
R4
R1
C3
R3
MAX4165
MAX4166
MAX4165 TRANSISTOR COUNT: 230
MAX4166 TRANSISTOR COUNT: 230
MAX4167 TRANSISTOR COUNT: 462
MAX4168 TRANSISTOR COUNT: 462
MAX4169 TRANSISTOR COUNT: 924
PART
MAX4167 EPA
MAX4167ESA
MAX4168 EPD -40°C to +85°C
-40°C to +85°C
-40°C to +85°C
TEMP. RANGE
PIN-
PACKAGE
8 Plastic DIP
8 SO
14 Plastic DIP
MAX4168ESD -40°C to +85°C 14 SO
SOT
TOP
MARK
—
—
—
—
MAX4168EUB
MAX4169 EPD -40°C to +85°C
-40°C to +85°C 10 µMAX
14 Plastic DIP
MAX4169ESD -40°C to +85°C 14 SO
—
—
—
Package Information
8LUMAXD.EPS
