MAX4165–MAX4169
High-Output-Drive, Precision, Low-Power, Single-
Supply, Rail-to-Rail I/O Op Amps with Shutdown
______________________________________________________________________________________ 13
SHDN
(1V/div)
OUT
(1V/div)
MAX4165-fig12
TIME (5 µ s/div)
Figure 12. Shutdown Output Voltage Enable/Disable
SHDN
(1V/div)
I CC
(1mA/div)
MAX4165-fig13
TIME (50 µ s/div)
Figure 13. Shutdown Enable/Disable Supply Current
V
CC
(1V/div)
OUT
(2V/div)
MAX4165-fig14
TIME (5 µ s/div)
Figure 14. Power-Up/Down Output Voltage
V CC
(1V/div)
I
EE
(1mA/div)
MAX4165-fig15
TIME (5 µ s/div)
Figure 15. Power-Up/Down Supply Current
