MAX4249–MAX4257
UCSP, Single-Supply, Low-Noise,
Low-Distortion, Rail-to-Rail Op Amps
4 _______________________________________________________________________________________
ELECTRICAL CHARACTERISTICS (continued)
(V
DD
= 5V, V
SS
= 0, V
CM
= 0, V
OUT
= V
DD
/2, R
L
tied to V
DD
/2, SHDN = V
DD
, T
A
= -40°C to +85°C, unless otherwise noted. Typical
values are at T A = +25°C.) (Notes 2, 3)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
MAX4250–MAX4254 6.7
Settling Time
To 0.01%, V OUT
= 2V step
MAX4249/MAX4255/
MAX4256/MAX4257
1.6
µs
MAX4251/MAX4253 0.8
Delay Time to Shutdown t SH
I VDD = 5% of
normal
operation
MAX4249/MAX4256 1.2
µs
MAX4251/MAX4253 8
Delay Time to Enable t EN
V OUT = 2.5V,
V OUT settles to
0.1% MAX4249/MAX4256 3.5
µs
Power-Up Delay Time t PU V DD = 0 to 5V step, V OUT stable to 0.1% 6 µs
Note 2: SHDN is available on the MAX4249/MAX4251/MAX4253/MAX4256 only.
Note 3: All device specifications are 100% tested at T
A = +25°C. Limits over temperature are guaranteed by design.
Note 4: Guaranteed by the PSRR test.
Note 5: Offset voltage prior to reflow on the UCSP.
Note 6: Guaranteed by design.
Note 7: Lowpass-filter bandwidth is 22kHz for f = 1kHz and 80kHz for f = 20kHz. Noise floor of test equipment = 10nV/
√Hz.
