MAX9500/MAX9501
Triple-Channel HDTV Filters
_______________________________________________________________________________________ 3
ELECTRICAL CHARACTERISTICS—MAX9500 (Single Supply) (continued)
(V CC = 5V, R L = ∞, T
A = T MIN to T MAX , unless otherwise noted. Typical values are at T A = +25°C.) (Note 1)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Nonlinearity NL 5-step staircase 0.4 %
Channel Delay t D
Difference in time between the 50% point of
the output signals, Y to Pb and Y to Pr
< 1 ns
Group Delay GD
100kHz ≤ f ≤ 20MHz, V
YOUT = V PbOUT =
V PrOUT = 2V P-P
26 ns
Group-Delay Variation ∆GD
100kHz ≤ f ≤ 20MHz, V
YOUT = V PbOUT =
V PrOUT = 2V P-P
< 10 ns
Channel-to-Channel Group-Delay
Matching
∆GD
CH-CH
V YOUT = V PbOUT = V PrOUT = 2V P-P , Y to Pb
and Y to Pr, 1MHz ≤ f ≤ 20MHz
0.2 ns
Peak Signal-to-RMS Noise SNR 100kHz ≤ f ≤ 20MHz, V
IN = 1V P-P 60 dB
Power-Supply Rejection Ratio PSRR AC f = 100kHz, V RIPPLE = 200mV P-P 60 dB
Output Impedance Z O f = 30MHz 8 Ω
Input Capacitance C IN 1 pF
Capacitive-Load Drive C
L
No sustained oscillations 25 pF
ELECTRICAL CHARACTERISTICS—MAX9501 (Dual Supply)
(V CC = 5V, V EE = -5V, R L = ∞, T
A = T MIN to T MAX , unless otherwise noted. Typical values are at T A = +25°C.) (Note 1)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
DC CHARACTERISTICS
Positive Supply Voltage Range V CC Guaranteed by PSRR 4.5 5.0 5.5 V
Negative Supply Voltage Range V EE Guaranteed by PSRR -5.5 -5.0 -4.5 V
V CC Quiescent Supply Current
(Per Channel)
I CC 35 48 mA
V EE Supply Current
(Per Channel)
I
EE
6 9 mA
Input Voltage Range V IN Guaranteed by voltage gain 0 1.4 V
R L = 150 Ω to GND +5.5 +6 +6.4
Voltage Gain A V V IN = 0 to 1.4V
R L = 75 Ω to GND +5.5 +6 +6.4
dB
Gain Matching ∆A
V Any two channels -0.5 0 +0.5 dB
Input Bias Current I B V IN = 0V 4 10 µA
Input Resistance R
IN
V
IN
= 0 to 1.4V 250 800 k Ω
Output Offset Voltage V OS V IN = 0V -0.2 0 +0.2 V
Power-Supply Rejection Ratio PSRR
V CC = 4.5V to 5.5V, V IN = 1.4V,
V EE = -4.5V to -5.5V
40 60 dB
