MAX6505–MAX6508
Dual Trip SOT Temperature Switches
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
CC
= +2.5V to +5.5V, R
PULLUP
= 100k
Ω (MAX6505/MAX6507 only), T
A
= -40
°C to +125°C, unless otherwise noted. Typical values
are at T
A
= +25°C and V
CC
= +5V, unless otherwise noted.) (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Supply Voltage (V
CC
to GND) ..................................-0.3V to +6V
S1, S0 to GND ............................................-0.3V to (V
CC
+ 0.3V)
All Other Pins to GND.................................-0.3V to (V
CC
+ 0.3V)
Input/Output Current, All Pins...........................................±20mA
Continuous Power Dissipation (T
A
= +70°C)
6-Pin SOT23 (derate 7.1mW/°C above +70°C)...........571mW
Operating Temperature Range
(T
MIN
to T
MAX
) ..............................................-40°C to +125°C
Thermal Resistance (
Θ
JA
)..............................................115°C/W
Storage Temperature Range .............................-65°C to +150°C
Maximum Die Temperature..............................................+150°C
Lead Temperature (soldering, 10s) .................................+300°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Supply Voltage Range
V
CC
2.5
5.5
V
S0 = S1 = GND
MAX6505/
MAX6506
40
80
Supply Current
I
CC
S0 = GND
MAX6507/
MAX6508
30
60
µA
-40
°C to 0 ° C -5.5
±0.5
5.5
0
°C to +95 ° C -3.5
±0.5
3.5
Temperature Threshold
Accuracy (Note 2)
∆T
TH
+95
°C to +125 ° C -4
±0.5
4
°C
S1 = GND, S0 = GND
5
S1 = GND, S0 = V
CC
10
S1 = V
CC
, S0 = GND
20
Delta Temperature
(T
ALARM
-T
WARNING
)
MAX6505/MAX6506
∆T
AW
S1 = V
CC
, S0 = V
CC
30
°C
ALARM (MAX6505/MAX6506)
2
∆T
AW
= 5
°C or
10
°C
5
WARN
(MAX6505/MAX6506)
∆T
AW
= 20
°C or
30
°C
10
S0 = GND
2
Temperature Threshold
Hysteresis (Note 3)
T
HYST
OK, OVER
(MAX6507/MAX6508)
S0 = V
CC
10
°C
V
IH
0.8 x
V
CC
Logic Input Levels (S1, S0)
V
IL
0.8
V
I
SOURCE
= 500
µA, V
CC
> 2.5V
0.8 x
V
CC
Output Voltage High
(MAX6506/MAX6508)
V
OH
I
SOURCE
= 800
µA,V
CC
> 4.5V
V
CC
-1.5
V
I
SINK
= 3.2mA, V
CC
> 2.5V
0.5
Output Voltage Low
V
OL
I
SINK
= 5mA, V
CC
> 4.5V
0.5
V
