MAX5304
10-Bit Voltage-Output DAC
in 8-Pin µMAX
_______________________________________________________________________________________ 5
2 µs/div
OUT
AC-COUPLED
10mV/div
CODE = 512
DIGITAL FEEDTHROUGH (f SCLK = 100kHz)
MAX5304-11a
SCLK
2V/div
CS = 5V
____________________________Typical Operating Characteristics (continued)
(V
DD
= +5V, R L = 5k Ω, C
L = 100pF, T
A
= +25°C, unless otherwise noted.)
10 µs/div
MAJOR-CARRY TRANSITION
MAX5304-10a
OUT
AC-COUPLED
100mV/div
CS
5V/div
10 µs/div
DYNAMIC RESPONSE
MAX5304-12a
OUT
1V/div
GND
GAIN = +2V/V, SWITCHING FROM CODE 0 TO 1005
