MAX8727

TFT-LCD Step-Up DC-DC Converter

2

_______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

ELECTRICAL CHARACTERISTICS

(V

IN

= V

SHDN

= 3V, FREQ = GND, T

A

= 0°C to +85°C. Typical values are at T

A

= +25°C, unless otherwise noted.) (Note 1)

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

LX to GND ..............................................................-0.3V to +26V
IN, SHDN, FREQ, FB to GND ...................................-0.3V to +6V
COMP, SS to GND .........................................-0.3V to V

IN

+ 0.3V

LX Switch Maximum Continuous RMS Current .....................2.4A
Continuous Power Dissipation (T

A

= +70

°C)

10-Pin Thin DFN (derate 24.4mW/

°C above +70°C) ....1951mW

Operating Temperature Range ...........................-40

°C to +85°C

Junction Temperature ......................................................+150

°C

Storage Temperature Range .............................-65

°C to +160°C

Lead Temperature (soldering, 10s) .................................+300

°C

PARAMETER

CONDITIONS

MIN

TYP

MAX

UNITS

V

OUT

< 18V

2.6

5.5

Input Voltage Range

18V < V

OUT

< 24V

4.0

5.5

V

Output Voltage Range

24

V

IN Undervoltage-Lockout
Threshold

V

IN

rising, typical hysteresis is 50mV

2.20

2.38

2.57

V

V

FB

= 1.3V, not switching

0.225

0.440

IN Quiescent Current

V

FB

= 1.0V, switching

2

5

mA

IN Shutdown Current

SHDN = GND

0.1

10.0

µA

ERROR AMPLIFIER

FB Regulation Voltage

Level to produce V

COMP

= 1.24V

1.22

1.24

1.26

V

FB Input Bias Current

V

FB

= 1.24V

50

125

250

nA

FB Line Regulation

Level to produce V

COMP

= 1.24V, V

IN

= 2.6V to 5.5V

0.05

0.15

%/V

Transconductance

100

200

300

µS

Voltage Gain

700

V/V

Shutdown FB Input Voltage

SHDN = GND

0.05

0.10

0.15

V

OSCILLATOR

FREQ = GND

540

640

740

Frequency

FREQ = IN

1000

1220

1500

kHz

Maximum Duty Cycle

87

90

93

%

n-CHANNEL MOSFET

Current Limit

V

FB

= 1V, 75% duty cycle

3.0

3.8

4.6

A

On-Resistance

125

250

Leakage Current

V

LX

= 24V

30

45

µA

Current-Sense Transresistance

0.11

0.21

0.31

V/A

SOFT-START

Reset Switch Resistance

100

Charge Current

V

SS

= 1.2V

2.5

4.5

7.5

µA
