MAX8727

Input Capacitor Selection

The input capacitor (C

IN

) reduces the current peaks

drawn from the input supply and reduces noise injection
into the IC. A 10µF ceramic capacitor is used in the typi-
cal operating circuit (Figure 1) because of the high
source impedance seen in typical lab setups. Actual
applications usually have much lower source imped-
ance since the step-up regulator often runs directly from
the output of another regulated supply. Typically, C

IN

can be reduced below the values used in the typical
operating circuit. Ensure a low noise supply at IN by
using adequate C

IN

. Alternatively, greater voltage varia-

tion can be tolerated on C

IN

if IN is decoupled from C

IN

using an RC lowpass filter (see R3 and C3 in Figure 1).

Rectifier Diode Selection

The MAX8727’s high switching frequency demands a
high-speed rectifier. Schottky diodes are recommend-
ed for most applications because of their fast recovery
time and low forward voltage. The diode should be
rated to handle the output voltage and the peak switch
current. Make sure that the diode’s peak current rating
is at least I

PEAK

calculated in the Inductor Selection

section and that its breakdown voltage exceeds the
output voltage.

Output Voltage Selection

The MAX8727 operates with an adjustable output from
V

IN

to 24V. Connect a resistive voltage-divider from the

output (V

MAIN

) to GND with the center tap connected to

FB (see Figure 1). Select R2 in the 10k

Ω to 50kΩ range.

Calculate R1 with the following equation:

where V

FB

, the step-up regulator’s feedback set point,

is 1.24V (typ). Place R1 and R2 close to the IC.

Loop Compensation

The voltage feedback loop needs proper compensation
to prevent excessive output ripple and poor efficiency
caused by instability. This is done by connecting a
resistor (R

COMP

) and capacitor (C

COMP

) in series from

COMP to GND, and another capacitor (C

COMP2

) from

COMP to GND. R

COMP

is chosen to set the high-fre-

quency integrator gain for fast transient response, while
C

COMP

is chosen to set the integrator zero to maintain

loop stability. The second capacitor, C

COMP2

, is cho-

sen to cancel the zero introduced by output-capaci-
tance ESR. For optimal performance, choose the com-
ponents using the following equations:

For the ceramic output capacitor, where ESR is small,
C

COMP2

is optional. The best gauge of correct loop

compensation is by inspecting the transient response
of the MAX8727. Adjust R

COMP

and C

COMP

as neces-

sary to obtain optimal transient performance.

Soft-Start Capacitor

The soft-start capacitor should be large enough that it
does not reach final value before the output has
reached regulation. Calculate C

SS

to be:

where C

OUT

is the total output capacitance including

any bypass capacitor on the output bus, V

OUT

is the

maximum output voltage, I

INRUSH

is the peak inrush

current allowed, I

OUT

is the maximum output current

during power-up, and V

IN

is the minimum input voltage.

The load must wait for the soft-start cycle to finish
before drawing a significant amount of load current.
The duration after which the load can begin to draw
maximum load current is:

t

MAX

= 6.77 x 10

5

x C

SS

C

C

V

V

V

V

I

I

V

SS

OUT

OUT

IN

OUT

IN

INRUSH

OUT

OUT

>

Ч

Ч

Ч

Ч

Ч

Ч

⎜⎜

⎟⎟

21

10

6

2

R

V

V

C

L

I

C

V

C

I

R

C

R

L

I

V

V

COMP

IN

OUT

OUT

MAIN MAX

COMP

OUT

OUT

MAIN MAX

COMP

COMP

ESR

MAIN MAX

IN

OUT

.

(

)

(

)

(

)

Ч

Ч

Ч

Ч

Ч

Ч

Ч

Ч

Ч

Ч

Ч

315

10

0 0036

2

R

R

V

V

MAIN

FB

1

2

1

=

×

TFT-LCD Step-Up DC-DC Converter

10
