MAX6854–MAX6869
Nanopower µP Supervisory Circuits with
Optional Manual Reset, Watchdog Timer
14
______________________________________________________________________________________
RESET TIMEOUT PERIODS
TIMEOUT
OPTION
MIN
TYP
MAX
UNITS
D1
10
15
25
D2
40
60
80
D3
150
225
300
D4
1200
1800
2400
D5
300
450
600
D6
600
900
1200
ms
Table
4. Reset Timeout Periods
PART
TOP MARK
MAX6854UK16D3
AEFS
MAX6854UK23D3
AEFY
MAX6854UK26D3
AEFZ
MAX6854UK29D3
AEGA
MAX6854UK31D3
AEGB
MAX6856UK16D3
AEGR
MAX6856UK23D3
AEGS
MAX6856UK26D3
AEGT
MAX6856UK29D3
AEGU
MAX6856UK31D3
AEGV
MAX6861UK17
AEKO
MAX6861UK225
AEKS
MAX6861UK26
AEKP
MAX6861UK29
AEKQ
MAX6862UK17
AEOS
MAX6862UK225
AEOT
MAX6862UK26
AEOU
MAX6862UK29
AEOV
MAX6863UK17
AEOW
MAX6863UK225
AEOX
MAX6863UK26
AEOY
MAX6863UK29
AEOZ
MAX6864UK16D3S
AEGC
MAX6864UK23D3S
AEGD
MAX6864UK26D3S
AEGE
MAX6864UK29D3S
AEGF
MAX6864UK31D3S
AEGG
MAX6866UK16D3S
AEGW
MAX6866UK23D3S
AEGX
MAX6866UK26D3S
AEGY
MAX6866UK29D3S
AEFT
MAX6866UK31D3S
AEGZ
Table
5. Standard Versions
Ordering Information (continued)
PART
†
TEMP RANGE
PIN-PACKAGE
MAX6856
UK_ _D_-T*
-40°C to +85°C
5 SOT23-5
MAX6857
UK_ _D_-T*
-40°C to +85°C
5 SOT23-5
MAX6858
UK_ _D_-T*
-40°C to +85°C
5 SOT23-5
MAX6859
UK_ _D_-T*
-40°C to +85°C
5 SOT23-5
MAX6860
UK_ _D_-T*
-40°C to +85°C
5 SOT23-5
MAX6861
UK_ _-T
-40°C to +85°C
5 SOT23-5
MAX6862
UK_ _-T*
-40°C to +85°C
5 SOT23-5
MAX6863
UK_ _-T*
-40°C to +85°C
5 SOT23-5
MAX6864
UK_ _D_ _-T*
-40°C to +85°C
5 SOT23-5
MAX6865
UK_ _D_ _-T*
-40°C to +85°C
5 SOT23-5
MAX6866
UK_ _D_ _-T
-40°C to +85°C
5 SOT23-5
MAX6867
UK_ _D_ _-T*
-40°C to +85°C
5 SOT23-5
MAX6868
UK_ _D_ _-T*
-40°C to +85°C
5 SOT23-5
MAX6869
UK_ _D_ _-T*
-40°C to +85°C
5 SOT23-5
†Insert reset threshold suffix (see Table 2, Threshold Suffix
Guide) after UK. Insert the number corresponding to the desired
reset timeout period (see Table 4, Reset Timeout Period) after
“D.” Insert the letter corresponding to the desired watchdog
timeout period (S or L, see Table 3) into the blank following the
reset timeout period suffix for the MAX6864–MAX6869.
Note: Sample stock is generally held on standard versions
only (see Table 5, Standard Versions Table). Standard versions
have an order increment of 2500 pieces. Nonstandard versions
have an order increment of 10,000 pieces. Contact factory for
availability of nonstandard versions.
*Future product—Contact factory for availability.
