MAX16055
Ultra-Small, Hex Voltage,
Microprocessor Supervisor
Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are
implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.
Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600 _____________________ 9
© 2009 Maxim Integrated Products is a registered trademark of Maxim Integrated Products, Inc.
Chip Information
PROCESS: BiCMOS
Selector Guide
NOMINAL INPUT VOLTAGE (V) PART*
(SUFFIX IN BOLD) IN1 IN2 IN3 IN4 IN5 IN6
MAX16055A 3.3 2.5 1.5 1.8 1.2 0.9
MAX16055B 3.3 3.0 1.8 1.5 1.1 1.0
MAX16055C 3.3 ADJ ADJ 1.8 ADJ ADJ
MAX16055D 3.3 ADJ 1.5 ADJ ADJ ADJ
MAX16055E 3.3 2.5 ADJ 1.8 ADJ ADJ
MAX16055F 3.3 2.5 1.5 ADJ ADJ ADJ
MAX16055G 3.3 2.5 ADJ ADJ ADJ ADJ
MAX16055H 3.3 ADJ ADJ ADJ ADJ ADJ
MAX16055I 2.5 ADJ ADJ ADJ ADJ ADJ
MAX16055J 3.3 3.3 2.5 1.2 1.5 1.2
Package Information
For the latest package outline information and land patterns, go
to
www.maxim-ic.com/packages .
PACKAGE TYPE PACKAGE CODE DOCUMENT NO.
10 µMAX U10+2 21-0061
* Adjustable voltage is based on the 0.5V internal threshold. External threshold voltage can be set using an external resistor-divider.
(V ADJ = 0.500V typ).
