MAX16055
Ultra-Small, Hex Voltage,
Microprocessor Supervisor
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
IN1
= 1V to 5.5V, T
A
= -40°C to +125°C, unless otherwise noted. Typical values are at V
IN1
= 3.3V, T
A
= +25°C.) (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
RESET, TOL, MR, IN_ to GND ..................................-0.3V to +6V
Input/Output Current (all pins) ............................................20mA
Continuous Power Dissipation (TA = +70°C)
10-Pin µMAX (derate 5.6mW/°C above +70°C) ...........444mW
Operating Temperature Range .........................-40°C to +125°C
Storage Temperature Range .............................-65°C to +150°C
Junction Temperature ......................................................+150°C
Lead Temperature (soldering, 10s) .................................+300°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNIT
Operating Voltage Range
V
IN1
(Note 2)
1.0
5.5
V
V
IN_
= nominal input voltage (for IN2–IN6;
3.3V, 3.0V, 2.5V, 1.8V, 1.5V, 1.2V, 1.1V,
1.0V, 0.9V supplies)
25
40
V
IN1
= nominal input voltage (for +3.3V IN1
supply)
55
115
Input Current (Note 3)
I
IN_
V
IN_
= 0 to 0.5V or V
ADJ
(for adjustable
thresholds)
-0.1
+0.1
µA
3.3V, TOL = GND
3.00
3.08
3.15
3.3V, TOL = V
IN1
2.85
2.93
3.00
3.0V, TOL = GND
2.70
2.78
2.85
3.0V , TOL = V
IN1
2.55
2.63
2.70
2.5V, TOL = GND
2.25
2.32
2.38
2.5V, TOL = V
IN1
2.13
2.19
2.25
1.8V, TOL = GND
1.62
1.67
1.71
1.8V, TOL = V
IN1
1.53
1.58
1.62
1.5V, TOL = GND
1.355
1.389
1.425
1.5V, TOL = V
IN1
1.283
1.316
1.350
1.2V, TOL = GND
1.084
1.112
1.140
1.2V, TOL = V
IN1
1.027
1.053
1.08
1.1V, TOL = GND
0.993
1.019
1.045
1.1V, TOL = V
IN1
0.941
0.965
0.99
1.0V, TOL = GND
0.903
0.926
0.95
1.0V, TOL = V
IN1
0.856
0.878
0.90
0.9V , TOL = GND
0.813
0.834
0.855
Threshold Voltage
V
TH
V
IN_
decreasing
0.9V, TOL = V
IN1
0.770
0.790
0.810
V
