MAX16055
Ultra-Small, Hex Voltage,
Microprocessor Supervisor
_______________________________________________________________________________________ 3
Note 1: 100% production tested at T A = +25°C. Limits over temperature guaranteed by design.
Note 2: The devices are powered from IN1.
Note 3: Monitored IN1 voltage is also the device power supply.
Note 4: RESET output is guaranteed to be in the correct state for IN1 or IN2 falling down to 1V.
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNIT
TOL = GND 0.491 0.5 0.506
Adjustable Threshold V TH V IN_ decreasing
TOL = V CC 0.465 0.472 0.479
V
Reset Threshold Hysteresis V HYST V IN_ increasing relative to V IN_ decreasing 0.3 %V TH
Reset Threshold Temperature
Coefficient
60 ppm/°C
IN_ to Reset Delay t RD
V IN_ falling at 10mV/µs from (V TH + 50mV)
to (V
TH
- 50mV)
20 µs
Reset Timeout Period t RP 140 200 280 ms
V IN1 = 5V, I SINK = 2mA 0.3
V IN1 = 2.5V, I SINK = 1.2mA 0.4 RESET Output Low (Note 4) V OL
V IN1 = 1.0V, I SINK = 50µA 0.3
V
RESET Output High V OH
V IN1 > 2.55V, I SOURCE = 6µA (min), RESET
not asserted
0.8 x
V IN1
V
RESET Output High Source
Current
I OH V IN1 > 2.55V, RESET not asserted 70 µA
TOL Input Current TOL = IN1 100 nA
MR, TOL Input Voltage Low V IL
0.3 x
V IN1
V
MR, TOL Input Voltage High V IH
0.7 x
V IN1
V
MR Minimum Pulse Width 1 µs
MR Glitch Rejection 100 ns
MR-to-RESET Delay 200 ns
MR Pullup Resistance 10 20 33 k Ω
ELECTRICAL CHARACTERISTICS (continued)
(V IN1 = 1V to 5.5V, T A = -40°C to +125°C, unless otherwise noted. Typical values are at V IN1 = 3.3V, T A = +25°C.) (Note 1)
