Modulation parameters
TC Electronic TonePrint Editor ■ Manual for software version 1 .0 11
Through-Zero-Flanger parameter
Parameter range: 0 to 1023
When you set the Modulation Type parameter to
TZFlanger, delay line 1 becomes the “dry” part of
the signal . In that case, use the Through-Zero-
Flanger parameter to set the level ratio between
delay line 1 and delay line 2 .
Speed parameter
Parameter range: 61 .5 mHz (Millihertz) to 20 Hz
Use the Speed parameter to set the speed of
the chosen modulation effect . As setting of 1 Hz
means that one modulation cycle takes one se-
cond .
Depth 1 parameter
Parameter range: 0 to 100 %
Use the Depth 1 parameter to specify the inten-
sity of the effect . The value represents the ampli-
tude of the waveform modulating the signal .
When you have set Modulation Type to TZFlang-
er, you should set the Depth 1 parameter to a
value lower than Depth 2 .
Depth 2 parameter
Parameter range: 0 to 100 %
The Depth 2 parameter is only applicable when
you have set Modulation Type to TriChorus or
TZFlanger .
In TriChorus mode, the Depth 2 parameter speci-
fies the intensity of the second chorus module . In
TZFlanger mode, the Depth 2 parameter speci-
fies the intensity of the second flange module .
The value represents the amplitude of the second
waveform modulating the signal .
Depth 3 parameter
Parameter range: 0 to 100 %
The Depth 3 parameter is only applicable when
you have set Modulation Type to TriChorus .
In TriChorus mode, the Depth 3 parameter speci-
fies the intensity of the third chorus module .
The value represents the amplitude of the third
waveform modulating the signal .
HiCut parameter
Parameter range: 20 Hz to 20 kHz
Use the HiCut parameter to reduce the high-end
frequencies in the modulation effect . Try using
this parameter if you feel the effect is too domi-
nant in your sound and turning down the Mix or
Output Level parameters doesn’t attenuate the
effect as intended .
Mix parameter
Parameter range: 0 to 100 %
Use the Mix parameter to set the relationship be-
tween the level of the dry signal and the level of
the modulation effect . If you have set Kill dry in
the Router section to On, this parameter has no
effect .
Output Level parameter
Parameter range: -100 to 0 dB
Use the Output Level parameter to set the overall
output level for the modulation effect .
Delay Time 1 parameter
Parameter range: 0 .1 to 50 ms
As described earlier, a chorus or flanger is basi-
cally a delay being modulated by an LFO . Use
the Delay Time 1 parameter to change the length
of that delay . A typical chorus uses delay times
around 10 ms, while a flanger uses delays around
5 ms .
Although this is not how a chorus is normally
used, you may enjoy the “slap-back” sound re-
sulting from longer Delay Time values in the 30
to 50 ms range .
Delay Time 2 parameter
Parameter range: 0 .1 to 50 ms
The Delay Time 2 parameter is only applicable
when you have set Modulation Type to TriChorus
or TZFlanger .
In TriChorus mode, the Delay Time 2 parameter
specifies the length of the delay for the second
chorus module .
In TZFlanger mode, the Delay Time 2 parameter
specifies the length of the delay for the second
flange module .
