9062-OM (V4.6) 9062 PRODUCT MANUAL 1-15
Introduction
9062 Functional Description
Loudness Processor (Option +LP)
Note: Loudness processor function is an optional licensable feature. This function
and its controls appear only when a license key is entered and activated.
(This option (identified in Cobalt
® price lists as +LP) can be purchased upon
initial order, or field-activated using a key string which is sent to you when this
option is purchased.)
If your card was purchased with option +LP , loudness processor manual
supplement “5.1 and Stereo Loudness Processing Options for Compass ®
Cards (+LP51, +LP20) Manual Supplement” (OPT-SW-LP-MS) is included
in your documentation package. Supplement OPT-SW-LP-MS can be
downloaded from our website or requested using the Cobalt contact
information in this manual.
Tone Generator Function
The 9062 contains four built-in tone generators (Tone Generator 1 thru Tone
Generator 4). Each of the four tone generators can be set to a different
frequency, and are available as audio sources for the embedded audio outputs.
18 discrete sine wave frequencies are available, ranging from 50 Hz to 16 kHz
(default frequency is 1.0 kHz).
User Control Interface
Figure 1-7 shows the user control interface options for the 9062. These
options are individually described below.
Note: All user control interfaces described here are cross-compatible and can oper-
ate together as desired. Where applicable, any control setting change made
using a particular user interface is reflected on any other connected interface.
• Built-in Card Edge User Interface – Using the built-in card edge
controls and display, card control settings can be set using a front
panel menu which is described in Chapter 3,“Operating Instructions”.
Note: Some of the 9062 functions described in this manual are available only when
using the DashBoard™, or Cobalt
® OGCP-9000 or OGCP-9000/CC Remote
Control Panel user interfaces.
• DashBoard™ User Interface – Using DashBoard™, the 9062 and
other cards installed in openGear®
1
frames can be controlled from a
computer and monitor.
DashBoard™ allows users to view all frames on a network with
control and monitoring for all populated slots inside a frame. This
simplifies the setup and use of numerous modules in a large
installation and offers the ability to centralize monitoring. Cards
define their controllable parameters to DashBoard™, so the control
interface is always up to date.
1. openGear® is a registered trademark of Ross Video Limited. DashBoard™ is a trademark of Ross
Video Limited.
