mODULATION SLOTS

SOURCE

The

SOURCE is a constantly changing signal that is used to

create mild to extreme modulation.

Touch the

SOURCE mENU to select a source.

OFF: (A source is not necessary). You can use the CONTROL
to manipulate a destination, but a positive or negative value
must be applied to the

AmOUNT.

LFO: Applies the LFO to the DESTINATION.

mOD: Applies the mODULATION ENVELOPE to the DESTINATION.

POSITION-X: Applies modulation according to a voice’s X position on the X/Y GRID.

POSITION-Y: Applies modulation according to a voice’s Y position on the X/Y GRID.

SOURCE AmOUNT

The

AmOUNT control scales the maximum amount of

modulation sent from the

SOURCE to the CONTROL

DESTINATION.

The

AmOUNT knob is bipolar and can be used to scale or

invert the selected source’s modulation amount. A positive
or negative value must be assigned or nothing will occur.

NOTE: Double tapping the Amount Knob returns it to 0.
