ESR tan δ Max. Ripple Current
Capacitance Case DCL
@ 100Khz max. @ 100kHz mA
μF Size Nemco Part No. μA max.
max. m
Ω
(%) (milliamps)
(microfarads) (milliohms) (microamps)
25°C 85°C 125°C
PART NUMBERS & SPECIFICATIONS
16 V DC @ 85°C
(10 V DC @ 125°C)
2.2 BL 2000 LSR2.2 / 16BL _2000 0.5 6 200 180 80
10.0 BL 800 LSR10 / 16BL _ 800 1.6 8 316 285 126
10.0 BL 1000 LSR10 / 16BL _1000 1.6 8 283 255 113
10.0 CL 500 LSR10 / 16CL _ 500 1.6 6 424 382 170
10.0 CL 600 LSR10 / 16CL _ 600 1.6 6 387 349 155
22.0 CL 500 LSR22 / 16CL _ 500 3.5 6 424 382 170
33.0 CL 140 LSR33 / 16CL _ 140 5.3 6 802 722 321
33.0 CL 175 LSR33 / 16CL _ 175 5.3 6 717 645 287
33.0 CL 250 LSR33 / 16CL _ 250 5.3 6 600 540 240
33.0 CL 400 LSR33 / 16CL _ 400 5.3 6 474 427 190
33.0 CL 500 LSR33 / 16CL _ 500 5.3 6 424 382 170
33.0 DL 300 LSR33 / 16DL _ 300 5.3 6 645 581 258
33.0 DL 400 LSR33 / 16DL _ 400 5.3 6 559 503 224
47.0 CL 200 LSR47 / 16CL _ 200 7.5 6 671 604 268
47.0 DL 250 LSR47 / 16DL _ 250 7.5 6 707 636 283
68.0 DL 150 LSR68 / 16DL _ 150 10.9 6 913 822 365
68.0 DL 200 LSR68 / 16DL _ 200 10.9 6 791 712 316
68.0 DL 250 LSR68 / 16DL _ 250 10.9 6 707 636 283
100.0 DL 100 LSR100 / 16DL _ 100 16.0 8 1118 1006 447
100.0 DL 150 LSR100 / 16DL _ 150 16.0 8 913 822 365
100.0 DL 200 LSR100 / 16DL _ 200 16.0 8 791 712 316
150.0 DL 200 LSR150 / 16DL _ 200 24.0 15 791 712 316
20 V DC @ 85°C
(13 V DC @ 125°C)
1.0 XL 6000 LSR1 / 20XL _ 6000 0.5 4 96 86 38
1.0 AL 6000 LSR1 / 20AL _ 6000 0.5 4 104 94 42
1.0 BL 2000 LSR1 / 20BL _ 2000 0.5 4 200 180 80
10.0 CL 250 LSR10 / 20CL _ 250 2.0 6 600 540 240
10.0 CL 500 LSR10 / 20CL _ 500 2.0 6 424 382 170
25 V DC @ 85°C
(17 V DC @ 125°C)
1.0 XL 2500 LSR1 / 25XL _ 2500 0.5 4 148 133 59
1.0 XL 4000 LSR1 / 25XL _ 4000 0.5 4 117 106 47
33.0 DL 200 LSR33 / 25DL _ 200 8.3 6 791 712 316
35 V DC @ 85°C
(23 V DC @ 125°C)
10.0 DL 250 LSR10 / 35DL _ 250 3.5 6 707 636 283
15.0 DL 250 LSR15 / 35DL _ 250 5.3 6 707 636 283
22.0 DL 200 LSR22 / 35DL _ 200 7.7 6 791 712 316
_ Insert tolerance M (+20%) or K(+10%) to complete the Nemco part number
NEMCO reserves the right to supply a higher voltage rating, tighter tolerance and / or lower ESR in the same case size, to the same reliability standards.
Low Profile
Surface Mount Tantalum Capacitors
LSR nemco
.
