Nemco Electronics Packaging User Manual
Page 2
Packaging for Auto Insertion, In Accordance with EIA RS - 481
Surface mount capacitors are packaged in a clear plastic tape suitable for use on all types of tape fed
surface mount assembly equipment. Tape and Reel specifications comply to EIA RS - 481-1.
REEL
A = 178 mm (7”) Standard Reel Size
330 mm (13”) Reel Available on Request
B = 50 mm min. (1.97)
C = 13 mm + 0.5 (.51 + .02)
D = 21 mm + 0.8 (.827 + .031)
E =
2 mm + 0.5 (.079 + .02)
t
=
2 mm + 0.5 (.079 + .02)
W = 9.5 mm + 1.0 (.374 + .04) for 8 mm tape width
13 mm + 1.0 (.512 + .04) for 12 mm tape width
TAPE
Code
8 mm Tape
12 mm Tape
D
1.5 + 0.1
(.059 + .004)
1.5 + 0.1
(.059 + .004)
D1
1.0 min.
(.039 min.)
1.5 min.
(.059 min.)
E
1.75 + 0.1 (.069 + .004)
1.75 + 0.1 (.069 + .004)
F
3.5 + 0.05 (.138 + .002)
5.5 + 0.05 (.217 + .002)
G
1.75 min.
(.03 min.)
1.75 min.
(.03 min.)
P2
2 + 0.05
(.079 + .002)
2 + 0.05
(.079 + .002)
P0
4 + 0.1
(.157 + .004)
4 + 0.1
(.157 + .004)
W
8 + 0.3
(.315 + .012)
12 + 0.3)
(.472 + .012)
l Tape materials do not affect component solderability during storage.
l Carrier tape thickness < 0.4 mm.
l Cover tape nominal thickness: 75µm
l Nominal width of cover tape = 5.5 mm (8 mm tape)
= 9.5 mm (12 mm tape)
l All Nemco PCT and LSR series tantalum chips are supplied on standard 7” reels. 13” reels are available upon request.
Case Code
Component Tape
Standard
Available
NEMCO
Width
XL
2012-12
8 mm
4 mm
1.9 mm (.075)
2500
10000
A
3216-18
8 mm
4 mm
2.3 mm (.090)
2000
8000
AL
3216-12
8 mm
4 mm
1.9 mm (.075)
2500
10000
B
3528-21
8 mm
4 mm
2.6 mm (.102)
2000
8000
BL
3528-12
8 mm
4 mm
1.9 mm (.075)
2500
10000
C
6032-28
12 mm
8 mm
3.3 mm (.130)
500
3000
CL
6032-15
8 mm
4 mm
1.7 mm (.066)
1000
5000
D
7343-31
12 mm
8 mm
3.6 mm (.142)
500
2500
DL
7343-20
8 mm
4 mm
2.1 mm (.082)
1000
5000
H
7343-43
12 mm
8 mm
4.8 mm (.189)
400
1500
Z
7361-37
12 mm
8 mm
4.0 mm (.156)
400
1500
EIA
Pitch
Thickness Max.
7” (178 mm)
13” (330 mm)
IECQ
P + 0.1
K
Reel Quantity
Reel Quantity
Tantalum Capacitors
Types PCT and LSR
