Nemco, Low profile recommended reflow pad design – Nemco Electronics Soldering Notes User Manual
Page 3
Nemco
Series
Case Size
EIA IECQ
Pad Dimensions mm (inches)
Pad Layout
PSL
PL
PS
PW
MCT
CGT
P (0402)
1005-07
2.2 (0.087)
0.9 (0.039)
0.4 (0.016)
0.7 (0.028)
R (0603)
1608-10
2.8 (0.110)
1.1 (0.043)
0.6 (0.024)
1.0 (0.039)
PCT
LSR
XL (0805)
2012-12
2.7 (0.106)
1.0 (0.039)
0.8 (0.031)
1.6 (0.063)
A (1206)
3216-18
3.8 (0.150)
1.4 (0.055)
1.0 (0.039)
1.8 (0.071)
AL (1206)
3216-12
3.8 (0.150)
1.4 (0.055)
1.0 (0.039)
1.8 (0.071)
B
3528-21
4.0 (0.157)
1.4 (0.055)
1.2 (0.047)
2.8 (0.110)
BL
3528-12
4.0 (0.157)
1.4 (0.055)
1.2 (0.047)
2.8 (0.110)
C
6032-28
6.5 (0.256)
2.0 (0.079)
2.5 (0.098)
2.8 (0.110)
CL
6032-15
6.5 (0.256)
2.0 (0.079)
2.5 (0.098)
2.8 (0.110)
D
7343-31
8.0 (0.315)
2.0 (0.079)
4.0 (0.157)
3.0 (0.118)
DL
7343-20
8.0 (0.315)
2.0 (0.079)
4.0 (0.157)
3.0 (0.118)
H
7343-43
8.0 (0.315)
2.0 (0.079)
4.0 (0.157)
3.0 (0.118)
Z
7361-38
8.0 (0.315)
2.0 (0.079)
4.0 (0.157)
3.7 (0.146)
PW
PL
PS
PSL
Low Profile
Recommended Reflow Pad Design
nemco
.
