Wilwood Brake, Clutch and Throttle Pedal-w_o Throttle Link Description User Manual
Page 3
Page 3
Assembly Diagram and Parts List • Part Number 340-12410
1
2
3
4
5
6
7
8
9
10
11
12
1
1
1
2
2
1
1
2
1
1
1
1
330-12409
330-12415
230-12454
240-5047
240-1347
240-12451
230-12450
230-12455
230-12453
230-6317
230-1335
230-12452
ITEM NO.
PART NO.
DESCRIPTION
QTY
Figure 1. Typical Installation Configuration, For Rear Engine Cars, Part Number 340-12410
