Wilwood Powerlite Radial Mount - Manual

4700 Calle Bolero • Camarillo, CA 93012 • www.wilwood.com • Sales: 805 / 388-1188 • Fax: 805 / 388-4938
147 REV DATE: 12-13-07
BILLET
POWERLITE CALIPER
Caliper Highlights:
The Powerlite four piston radial mount caliper
combines pure race technology with a new
generation of Wilwood performance enhancements.
Its sleek profile, superior strength, and durability
in higher temperature applications are easily
adapted to a wide range of sports, rally, and off road
driving applications.
The strength of the Powerlite is a combination of
process and design. The process of stress-flow forging
re-aligns the metal's grain structure within the contour of the
caliper body. This eliminates the stresses and interruptions to
the internal grain structure that occur when machining a straight block
billet. The FEA generated radial transition design eliminates steps and
shoulders in the area between the piston housing body and the caliper bridges. Incorporating a radius in this critical
area substantially increases resistance to deflection and caliper separation under load. Structural deflection and
volume displacement tests have proven the efficiency of this innovative design. Without even considering the
overall greater strength and reliability of the billet forging, the reduction in overall deflection and fluid volume
displacement translate to increased clamping efficiency with less pedal travel. The bottom line is a firm pedal with
outstanding stopping power.
The superior strength of this innovative design is combined with a new generation of Wilwood performance features.
The Powerlite uses a new 7912 type brake pad that is supported from the top by Quick-clip pad retainers. This
feature eliminates the need for a pad support step in the bottom of the caliper and adds additional clearance for
mounting closer to the hub on small wheel and small rotor applications. The pad radius matches to rotor diameters
between 9.45" (240,0 mm) and 11.00" (279,4 mm), and the caliper fits easily inside many 13.00" (330,2) wheel
applications. The Quick-Clips also accommodate easy pad access without caliper removal. Brake pad compounds
are available to cover the full range of sport and competition applications.
Every caliper is equipped with Wilwood's SRS stainless steel bridge plates. The SRS plates eliminate the bridge wear
caused by pad gouging and extend the service life of the caliper body. The spring-loading action of the SRS plates
also eliminates pad rattle and dampens the vibration harmonics that contribute to squeal under braking. Internal fluid
passages eliminate the need for external tubes. Four corner bleed screws assure simple and effective air
evacuation from the system and allow one caliper to be mounted in any front, rear, right or left position
ORDERING INFORMATION:
BORE SIZE DISC WIDTH PART NUMBER
1.38” 35,1 mm .79” - .86” 20,1 - 21,8 mm 120-8729
1.38” 35,1 mm .35” - .50” 2 8,9 - 12,7 mm 120-8726
1.25” 31,8 mm .79” - .86” 20,1 - 21,8 mm 120-8728
1.25” 31,8 mm .35” - .50” 2 8,9 - 12,7 mm 120-8725
1.00” 25,4 mm .79” - .86” 20,1 - 21,8 mm 120-8727
1.00” 25,4 mm .35” - .50” 2 8,9 - 12,7 mm 120-8724
