5. Assembling Sidewall Sheets

34

PNEG-4021 40 Series 18', 21' and 24' Diameter Bins

Figure 5B Caulking Detail as Viewed from Inside of the Bin

4. Use the supplied tube caulk to fill the larger gaps that occur with heavier gauges and laminated

gauges. See Caulking Detail for Laminated Quad Pattern Sheets

on Page 35

for details about caulk

laminated sidewall sheets.

Ref #

Description

C

10" (25.4 cm) Strip of Caulk

D

10" (25.4 cm) Strip of Caulk
