Diagonal “x” bracing configurations – Grain Systems Bucket Elevtors, Conveyors, Series II Sweeps PNEG-1412 User Manual
Page 17
PNEG-1412 Two Leg Towers
17
Diagonal “X” Bracing Configurations
“X”-Bracing is to be used in all upper sections of a tower.
All 20’-25’-30’ Tall Towers should all be “X”-braced, except for
the lower 10’ that is not “x” braced. (See examples above.)
All 35’ and taller towers should all be “X”-braced, except for
the lower 15’ that is not “X”-braced. (See examples above.)
