3. 30'-54' Roof Instructions
12
PNEG-1801 Special 30'-54' Diameter High Snow Roof Rafter Instructions
Special Rafter Instructions for 30' Diameter High Snow Roof
The 30' diameter high snow roof comes with 10 roof rafter assemblies and 10 purlins that are not included
in the 30° roof manual (PNEG-1092). Install one roof rafter per sidewall sheet. Please refer to the roof
manual for the complete roof assembly details.
NOTE: Each rafter has one section.
Figure 3B
See detail A
See detail C
and detail D
See detail B
See detail E
