14. Parts List
PNEG-257 12', 15', 18' and 21' Bulk Feed Tanks BFT and GHT Series 79
12' Diameter 45° Hopper Bin Hardware Specification Parts List
NOTE: Bolts listed first, nuts second for each usage.
Ref # Part # Description Qty
1
S-275
Bulk Tank Peak Ring to Roof Panels (Use 5/16" x 3/4" Hex Head Bin Bolts and
5/16" Hex Nuts.)
36
S-396 36
2
S-275
Roof Panel to Roof Panel (Use 5/16" x 3/4" Hex Head Bin Bolts and 5/16" Hex Nuts.)
240
S-396 240
3
S-275
Roof Panels to Top Sidewall Sheets (Use 5/16" x 3/4" Hex Head Bin Bolts and
5/16" Hex Nuts.)
144
S-396 144
4
S-275
Vertical Sidewall Sheet Seams (Use 5/16" x 3/4" Hex Head Bin Bolts and
5/16" Hex Nuts.)
Varies
S-396 Varies
5
S-275
Horizontal Sidewall Sheet Seams (Use 5/16" x 3/4" Hex Head Bin Bolts and
5/16" Hex Nuts.)
Varies
S-396 Varies
6
S-275
Leg to Sidewall Sheet (Use 5/16" x 3/4" Hex Head Bin Bolts and 5/16" Hex Nuts.)
(Bolt Heads to Inside of Tank)
96 or 168
S-396 96 or 168
7
S-277
Hopper Panels to Sidewall Sheet (Use 5/16" x 1-1/4" Hex Head Bin Bolts and
5/16" Hex Nuts.) (Bolt Head to Inside at Leg to Hopper to Sidewall Connection Only.)
288
S-396 288
8
S-4303
Vertical Hopper Seams (Use 5/16" x 3/4" Truss Head Bin Bolts and
5/16" Flanged Whiz Nuts.) (Bolt Heads to Inside of Tank.)
300
S-3611 300
9
S-4303
Hopper Collar to Hopper Panel (Use 5/16" x 3/4" Truss Head Bin Bolts
and 5/16" Flanged Whiz Nuts.) (Bolt Heads to Inside of Tank.) (16" Shown.)
36
S-3611 36
10
S-7927
Hopper Brace to Leg (Use 3/8" x 1" Flange Head Bolts and 3/8" Hex Nuts.)
8
S-456 8
11
S-7927
Cross Tie Brace to Leg (Use 3/8" x 1" Flange Head Bolts and 3/8" Hex Nuts.)
24
S-456 24
