PNEG-1324 72', 75', 78', 90' and 105' Cor-Lok and Cut-Lok Flooring
75' Full Floor Plank Layout Chart
The following plank lengths start at the sidewall and work toward the center of the bin. Refer to grandstand
support spacing
for support spacing.
37'-0.1/2" from center of bin to edge of first plank.
*** Plank is centered on middle.
Plank #
Side A
Center
Side B
1
8'-9"
2
15'-9"
3
19'-7"
4
23'-4"
5
26'-8"
6
29'-6"
7
32'-1"
8
34'-4"
9
36'-6"
10
18'-3"
20'-3"
11
19'-2"
21'-2"
12
20'-0"
22'-0"
13
20'-10"
22'-10"
14
21'-7"
23'-7"
15
22'-4"
24'-4"
16
23'-1"
25'-1"
17
23'-9"
25'-9"
18
24'-4"
26'-4"
19
24'-11"
27'-0"
20
25'-6"
27'-7"
21
26'-2"
28'-2"
22
26'-8"
28'-8"
23
27'-2"
29'-3"
24
27'-8"
29'-9"
25
28'-2"
30'-2"
26
28'-7"
30'-7"
27
29'-0"
31'-1"
28
29'-4"
31'-4"
29
29'-10"
31'-10"
30
30'-3"
32'-3"
31
30'-7"
32'-7"
32
30'-11"
32'-11"
Plank #
Side A
Center
Side B
33
31'-4"
33'-4"
34
31'-7"
33'-8"
35
31'-11"
33'-11"
36
32'-3"
34'-3"
37
32'-6"
34'-7"
38
32'-9"
34'-10"
39
33'-0"
35'-1"
40
33'-3"
35'-4"
41
33'-6"
35'-7"
42
33'-9"
35'-10"
43
34'-0"
36'-0"
44
34'-2"
36'-2"
45
34'-4"
36'-5"
46
34'-5"
36'-6"
47
34'-7"
36'-8"
48
34'-9"
36'-10"
49
34'-11"
37'-0"
50
35'-1"
37'-1"
51
35'-2"
37'-3"
52
35'-4"
37'-4"
53
35'-5"
37'-6"
54
35'-6"
37'-7"
55
35'-8"
37'-8"
56
35'-9"
37'-9"
57
35'-9"
37'-10"
58
35'-10"
37'-11"
59
35'-11"
37'-11"
60
35'-11"
38'-0"
61
36'-0"
38'-0"
62
36'-0"
38'-1"
63
36'-0"
38'-1"
64
36'-0" ***
38'-1" ***
