Banks Power Dodge Trucks: (Diesel ’98 - 02 5.9L Cummins ISB) Power Systems- Stinger & Git-Kit Systems (does not connect to pump wire) - Manual (Page 9)

29.
At the rear of the muffler, slip
a 4” clamp over the outlet of the
muffler. Install the tailpipe up over
the axle, and into the muffler outlet.
Place the hanger pins into the rubber
frame mounts behind the axle. Slip
the 5” Monster tailpipe tip on. keep
the wrapping on until installation is
complete. The tip should be rotated
so the clamp nut is pointing down.
Install the 5” tip so that it hangs past
the end of the tailpipe by 1” for fleet-
side trucks and 2
1 ⁄
2
” for duallies or
where aesthetically pleasing.
30.
Starting from the front of the
vehicle, tighten all exhaust system
attaching bolts and clamps. Make
sure each slip joint is fully inserted,
and that all frame mount hangers are
hanging in a forward position. See
Figure
3 .
ottomind inStallation
31.
For automatic transmission
models, locate and remove the
rubber plug mounted in the firewall
slightly above and to the right of
the steering shaft, as viewed facing
the firewall through the engine
compartment. Make a cross-shaped
incision in the plug and reinstall it in
the firewall. See Figure
4 .
For manual transmission models,
make an incision in the main wiring
loom grommet above the wire
bundle. Take care to not cut any
wiring. See Figure
4 .
32.
Remove three Phillips-head
screws from the trim panel below the
steering column and remove panel
by pulling directly toward the rear
of the vehicle. Retain the screws for
re-installation. Use caution to avoid
damaging the panel during removal.
33.
Insert the end of the provided
OttoMind wire loom with the 8-
and 10-pin connectors through
the grommet from the engine
compartment. Pull the Ottomind
wire loom from inside the cab until
approximately 18” of the wire loom
Figure 4
9 6 7 6 5 v . 5 . 0
| 9
