4
97226 v.1.0
PowerPDa LCD Properties
The screen of the PowerPDA can
be adjusted for brightness to
accommodate the ambient light
conditions as well as individual
preference. From the System Menu,
press the LcD Properties button (see
Figure 4). Read the instructions
provided and adjust the settings to
your liking.
Note: The PowerPDA has an automatic
shut down feature. Once the key is
turned off, the PowerPDA will detect
that a signal is no longer present
from the SpeedBrake and it will
automatically power down after a few
seconds. This is to prevent excessive
usage of the PDA battery. With the Key
in the “Run” position, the SpeedBrake
will be activated and all features will
be accessible.
SpeedBrake Modes
The SpeedBrake has three operating
modes; ON, SPEED CONTROL and
OFF. In the ON mode, the SpeedBrake
will activate and will downshift
the transmission and close the
turbocharger vanes to achieve braking
and decelerate your vehicle down to
15 MPH. In SPEED CONTROL mode,
the SpeedBrake varies the position of
the turbocharger vanes and selects an
appropriate gear in order to maintain a
pre-selected target speed. In the OFF
mode, the vehicle will behave as if the
SpeedBrake is not present.
oN Mode
Mode selection is achieved by
pressing the “UP” portion of the 5-way
navigation button (see Figure 1).
Toggle through the modes until the
SpeedBrake Mode display indicates
“ON” (see Figure 3).
Power
Operating
Gear
Engine
Temperature
Speed Brake
System Status
Vehicle Speed
Transmission
Temperature
SpeedBrake
Mode
On Screen
Alert Display
B rake Level/
Braking Speed
SpeedBrake
braking effort
Figure 3 System Monitor Screen
