BATTEST2 – MULTI-PURPOSE BATTERY TESTER WITH LCD DISPLAY
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm
the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialised
company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying the BATTEST2! Please read the manual thoroughly before bringing this device into service. If the
device was damaged in transit, don't install or use it and contact your dealer.
2. General Guidelines
• Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and the dealer
will not accept responsibility for any ensuing defects or problems.
• Do not use rechargeable batteries to power your BATTEST2.
• Only test one battery at the time.
• Do not modify or disassemble the device.
3. Use
1. To power the battery tester, remove the battery cap at the back of the device. Insert 1 x 1.5V AAA alkaline battery
respecting the polarity. Replace the battery cap.
2. Insert the battery you would like to test into the corresponding test channel (for CRV3, CR5 and CRP2 batteries,
9V, 3V and 1.5V button cells) or slot (CR2, CR123A, N, AA, AAA, C and D type batteries). Make sure the battery
is firmly placed respecting the polarity. The battery condition will be shown on the LCD display (see fig. below).
3. Remove the battery after checking.
REMARKS: Make sure the battery is correctly placed into the slot or the test channel. Remove the battery powering
the BATTEST2 when not in use to avoid battery leakage. Use a fresh alkaline battery to run the tester to
ensure accurate testing results.
4. The LCD Display
LCD Display
Battery Condition
1 – 5 marks (POOR) The battery is empty. Recharge a rechargeable battery or dispose of the battery
respecting the local rules.
6 – 10 marks (FAIR) Battery with limited power but can still be used for a limited time.
11 – 18 marks (GOOD) Battery has adequate power.
5. Technical Specifications
Power Supply 1 x 1.5V AAA battery
Dimensions 118 x 88 x 23mm
The information in this manual is subject to change without prior notice.
