Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.
There are no user-serviceable parts, apart from the fuse.
Contact your dealer for spare parts if necessary.
Replacing the Fuse
Only replace the fuse by a fuse of the same type and rating.
1. Before replacing the fuse, unplug the mains lead.
2. Unscrew the fuse holder on the rear panel of the base with an appropriate screwdriver.
3. Remove the old fuse and install the new fuse in the fuse holder.
4. Replace the fuse holder in the housing and tighten it.
9.
Technical Specifications
LX106
LX107
power supply
240 VAC 50 Hz
240 VAC 50 Hz
power consumption
75 W
120 W
DMX connection
3-pin XLR
3-pin XLR
light source
12 x high-power 10 W RGBW LEDs
18 x high-power 10 W RGBW LEDs
beam angle
17°
17°
luminous flux
18000 lm @ 1 m
20000 lm @ 1 m
dimensions
295 x 255 x 100 mm
335 x 310 x 110 mm
weight
3.5 kg
5 kg
Use this device with original accessories only. Velleman nv cannot be held responsible in the event
of damage or injury resulting from (incorrect) use of this device.
For more info concerning this product and the latest version of this manual, please visit our website
www.luxibel.com.
The information in this manual is subject to change without prior notice.
