LX106/LX107
V. 05 – 15/05/2013 4 ©Velleman nv
Familiarise yourself with the functions of the device before actually using it. Do not allow operation by
unqualified people. Any damage that may occur will most probably be due to unprofessional use of the
device.
All modifications of the device are forbidden for safety reasons. Damage caused by user modifications to
the device is not covered by the warranty.
Only use the device for its intended purpose. All other uses may lead to short circuits, burns, electroshocks,
lamp explosion, crash, etc. Using the device in an unauthorised way will void the warranty.
Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and the
dealer will not accept responsibility for any ensuing defects or problems.
Mechanical wear and LEDs are not covered by warranty.
A qualified technician should install and service this device.
Do not switch the device on immediately after it has been exposed to changes in temperature. Protect the
device against damage by leaving it switched off until it has reached room temperature.
This device is designed for professional use on stage, in discos, theatres, etc. The device should only be
used indoors with an alternating current of 240 VAC, 50 Hz.
Lighting effects are not designed for permanent operation: regular operation breaks will prolong their lives.
Use the original packaging if the device is to be transported.
Keep this manual for future reference.
4. Features
PAR projector with high power RGBW LEDs
extremely slim design
smooth dimming modes for perfect colour mixing
DMX control:
o
4 channels: RGBW
o 6 channels: RGBW, dimmer and shutter
o 10 channels: RGBW, dimmer, colour temperature, shutter, auto, speed, dimming curves
built-in programs
double bracket: can be used as a floor spot
sound-activated via built-in microphone.
5. Overview
Refer to the illustrations on page 2 of this manual.
LX106 LX107
1 bracket 11 bracket
2 hinges 12 DMX input
3 DMX output 13 hinges
4 DMX input 14 DMX output
5 built-in microphone + sensitivity regulator 15 built-in microphone + sensitivity regulator
6 control buttons 16 control buttons
7 display 17 display
8 power input 18 power input
9 power output 19 fuse holder
10 fuse holder 20 power output
6. Installation
Choose a suitable mounting spot. Mount the fixture in the desired angle using the included bracket. Connect the
power cord to the mains. Disconnect after use.
Mounting the Device
Have the device installed by a qualified person, respecting EN 60598-2-17 and all other applicable norms.
The carrying construction must be able to support 10 times the weight of the device for 1 hour without
deforming.
The installation must always be secured with a secondary attachment e.g. a safety cable.
