LX106/LX107
V. 05 – 15/05/2013 6 ©Velleman nv
Stand-Alone Mode with Built-in Program
To set the device to stand-alone mode with a built-in program:
1. Connect nothing to the DMX input [4,12] of the device.
2. Press
o P1: 15 colours, fading 0 % – 100 % – 0 %
o P2: 15 colours, fading 0 % – 100 %
o P3: 15 colours, fading 100 % – 0 %
o P4: colour macros, fading
o P5: loop running P1 – P4.
After you select a program, you set the speed of the program.
4. Use and to set the speed from (slow) to (fast).
5. Press to confirm.
Sound Control
To activate sound control:
1. Press
Stand-Alone Mode with Built-in Static Colour
To use one of the built-in static colours:
1. Connect nothing to the DMX input [4,12] of the device.
2. Press
C1 Red C6 Red + blue C11 Green + white
C2 Green C7 Green + blue C12 Red + blue + white
C3 Blue C8 Red + green + blue C13 Green + blue + white
C4 White C9 Red + white C14 Red + green + white
C5 Red + green C10 Blue + white C15 Red + green + blue + white
Stand-Alone Mode with Custom Static Colour
You can create a custom colour by adjusting the intensity of the red, green, blue, and white LEDs. Also, you can
specify a strobe rate with the custom colour.
To use a custom static colour:
1. Connect nothing to the DMX input [4,12] of the device.
2. Press
The intensity setting for the first colour appears, for example (red 50%).
3. Use and to set the intensity of the colour from 000 to 100 and press .
The intensity setting for the next colour appears.
4. Set the intensity for all colours ( for red, for green, for blue, for white) until you
have the desired output colour.
5. To set the strobe rate, press until appears on the display.
6. Use and to set the strobe rate (S0 to set the strobe off, S1 – S20 for strobe speed slow to
fast) and press .
Dimmer Adjustment
You can manually control the dimmer speed. To set up the desired dimmer speed:
1. Press
o : dimmer off.
o – : dimming speeds 1 to 3.
3. Press to confirm.
