LEDC12
V. 01 – 28/03/2013 6 ©Velleman nv
Mode Function Comment
7 Static white
8 Three-colour fast change Speed and brightness
are adjustable 9 Seven-colour fast change
10 Three-colour gradual
change
Speed is adjustable,
brightness is
not adjustable
11 Seven-colour gradual
change
12 Red strobe
Speed and
brightness
are adjustable
13 Blue strobe
14 Purple strobe
15 Green strobe
16 Yellow strobe
17 Cyan strobe
18 White strobe
19 R/B crossfade Speed is
adjustable,
brightness is
not adjustable
20 B/G crossfade
21 G/R crossfade
 To adjust brightness, press or .
 To adjust speed, press or .
7. Technical Specifications
power supply 12 - 24 VDC
maximum load 3 x 4 A
PWM frequency ± 900 Hz
external dimensions 86 x 86 x 13 mm
internal dimensions 57 x 65 x 24 mm
weight
150 g
caution output current of power supply must not
exceed 3 x 4 A.
Suitable power supplies:
144 W / 12 V or 288 W / 24 V.
Use this device with original accessories only. Velleman nv
cannot be held responsible in the event of damage or injury
