You can use the same starting address for a whole group of devices or enter an individual one for every
device.
•
When all devices have the same address, all the units will “listen” to the control signal on one particular
channel. In other words: changing the settings of one channel will affect all devices simultaneously. If you
set different addresses, each device will “listen” to a separate channel number. Changing the settings of
one channel will only affect the device in question.
•
In the case of the 4-channel VDPLPS36BP, you will have to set the start address of the first unit to 1, the
second unit to 5 (1 + 4), the third to 9 (5 + 4), and so on.
7.
Operation
7.1 DMX channels
Channel
Function
Channel 1
Dimmer / Strobe
Channel 2
Red
Channel 3
Green
Channel 4
Blue
7.2 Stand alone functions (dip switches)
DMX
dip switch 10 on
DMX on
dip switch 10 off
internal programs
Effects
dip switch 9 on
rainbow chase
3 – 8: speed adjust
dip switch 9 + 1 on
strobe slow
3 – 8: speed adjust
dip switch 9 + 1 + 2 on
red – blue chase
3 – 8: speed
Fixed colours
dip switch1 on
red dim 1
dip switch 2 on
red dim 2
dip switch 3 on
red full
dip switch 4 on
green dim 1
dip switch 5 on
green dim 2
dip switch 6 on
green full
dip switch 7 on
blue dim 2
dip switch 8 on
blue full
Combining these settings give mix colours. Example: 3 + 6 + 8 = white.
8.
Cleaning and Maintenance
•
All screws should be tightened and free of corrosion.
•
The housing, the lenses, the mounting supports and the installation location (e.g. ceiling, suspension,
trussing) should not be deformed, modified or tampered with e.g. do not drill extra holes in mounting
supports, do not change the location of the connections …
•
Mechanically moving parts must not show any signs of wear and tear.
•
The electric power supply cables must not show any damage. Have a qualified technician maintain the
device.
•
Disconnect the device from the mains prior to maintenance activities.
•
Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.
•
There are no user-serviceable parts, apart from the lamp and the fuse (see “Installation”).
•
Contact your dealer for spare parts if necessary.
