Unit 2
Channel From To
Description
6
0 7 Off
8 255 Colour selection: same as for head 1 (see channel 1)
7 0 255 Dimmer
8
0 8 Open
9 255 Strobe slow to fast
9 0 255 X-axis motor of head 2
10 0 255 Y-axis motor of head 2
Unit 3
Channel From To
Description
11
0 7 Off
8 255 Colour selection: same as for head 1 (see channel 1)
12 0 255 Dimmer
13
0 8 Open
9 255 Strobe slow to fast
14 0 255 X-axis motor of head 3
15 0 255 Y-axis motor of head 3
Unit 4
Channel From To
Description
16
0 7 Off
8 255 Colour selection: same as for head 1 (see channel 1)
17 0 255 Dimmer
18
0 8 Open
9 255 Strobe slow to fast
19 0 255 X-axis motor of head 4
20 0 255 Y-axis motor of head 4
8. Cleaning and Maintenance
• All screws should be tightened and free of corrosion.
• The housing, the lenses, the mounting supports and the installation location (e.g. ceiling, suspension,
trussing) should not be deformed, modified or tampered with; e.g. do not drill extra holes in mounting
supports, do not change the location of the connections…
• Mechanically moving parts must not show any signs of wear and tear.
• The electric power supply cables must not show any damage. Have a qualified technician maintain the
device.
• Disconnect the device from the mains prior to maintenance activities.
• Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.
• There are no user-serviceable parts, apart from the fuse.
• Contact your dealer for spare parts if necessary.
Replacing the Fuse
Only replace the fuse by a fuse of the same type and rating.
1. Before replacing the fuse, unplug the mains lead.
2. Wedge the fuse holder out of its housing with a flat-head screwdriver.
3. Remove the damaged fuse from its holder and replace with the exact same type of fuse.
4. Insert the fuse holder back in its place and reconnect power.
