VDPL4300SC
V. 01 – 19/07/2012 7 ©Velleman nv
DMX Channel Values
9 channel mode:
Channel From To Description
1
0 7 Off
8 200 Dimmer
201 247 Strobe
248 255 All on
2 1 255 RGBW colour mix
3 0 255 X-axis motor
4 0 255 Y-axis motor
5
0 7 Off
8 255 Run effect
6
0 7 Off
8 255 Run effect fast
7
0 7 Off
8 255 Motor running
8
0 7 Off
8 255 Motor running fast
9
0 127 Sound off
128 255 Sound on
20 channel mode:
Unit 1
Channel From To
Description
1
0 7 Off
8 24 Red
25 41 Green
42 57 Blue
58 74 White
75 90 Red green
91 107 Red blue
108 123 Red white
124 140 Green blue
141 156 Green white
157 173 Blue white
174 189 Red blue green
190 206 Blue green white
207 222 Red blue white
223 239 Red green white
240 255 Red green blue white
2 0 255 Dimmer
3
0 8 Open
9 255 Strobe slow to fast
4 0 255 X-axis motor of head 1
5 0 255 Y-axis motor of head 1
