PSS2010 / PSS4005 VELLEMAN - 3 -
PSS2010 / PSS4005 – DIGITAL SWITCHING POWER SUPPLY
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm
the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialized
company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying this switching power supply! Please read the manual thoroughly before bringing this device into
service. If the device was damaged in transit, don't use it and contact your dealer.
2. Technical Specifications
PSS2010 PSS4005
Output voltage 0-20Vdc ; 10mV steps 0-40Vdc ; 10mV steps
Output current 0-10A ; 10mA steps 0-5A ; 10mA steps
Operating voltage 230Vac ±10%
Power frequency 50Hz
Power consumption max. ±300VA
Power output max. ±200W
Voltage stability (U) with 100% load swing
≤10mV
Current stability with 100% load swing
≤5mA
Voltage stability with ±10% AC voltage change
≤0.05%
Current stability with ±10% AC voltage change
≤0.05%
Ripple at nominal load ±15mV rms
Display multi-line LCD with backlight
Fuse F1 6.3A / 250V (slow) (order code FU6.3N)
Fuse F2 1A / 250V (slow) (order code FU1N)
Weight ±3kg
Dimensions (W x H x D) ± 275x135x300mm
Operating temperature 0 → 40°C
Max. relative humidity ±80% non-condensing
Storage temperature -20 → +60°C
3. Controls and Connections
Front
1. Backlit LCD
2. Keypad
3. Adjustment wheel
4. 4mm safety socket for negative connection (-)
5. 4mm safety socket for positive connection (+)
6. 4mm safety socket for ground connection
7. Power switch (on/off)
