PS1503SB Rev.

01

16.10.2009

©Velleman nv

4

4. Notes

- This unit is short circuit protected. If a short circuit should occur, turn the power supply off and solve

the problem.

- Install or store the device in a clean and well-ventilated environment.

- Do not try to open the housing yourself. All repairs should be executed by a qualified technician.

- Disconnect the unit from the mains during maintenance.

- The unit can get very hot when you are using a high power output.

- If the unit is defective, the output may rise over the maximum rated voltage. Always keep an eye on

the load to prevent damage.

- This unit should be earthed properly.

5. Technical Specifications

input voltage

220 VAC ± 10 %; 50 Hz ± 2 Hz

output voltage

0 ~ 15 V continuously adjustable

output current

0 ~ 3 A continuously adjustable

ripple and noise

CV ≤ 1.0 mV RMS

CC

≤ 3 mA RMS

supply regulation

CV ≤ 1 x 10

-4

+ 0.5 mV

CC

≤ 2 x 10

-3

+ 6 mV

load regulation

CV ≤ 1 x 10

-4

+ 2 mV

CC

≤ 2 x 10

-3

+ 6 mV

accuracy voltage

± 1 % + 2 digits

accuracy current

± 2 % + 2 digits

protection current-limiting
operating temperature

0 ~ 40°C

operating humidity

< RH 80 %

operating atmospheric pressure

86 kPa ~ 104 kPa

autonomy

8 hrs of continuous operation

dimensions

225 x 95 x 160 mm

weight 2.5

kg

Use this device with original accessories only. Velleman nv cannot be held responsible in the

event of damage or injury resulted from (incorrect) use of this device. For more info

concerning this product, please visit our website www.velleman.eu. The information in this

manual is subject to change without prior notice.


© COPYRIGHT NOTICE

This manual is copyrighted. The copyright to this manual is owned by Velleman nv. All

worldwide rights reserved. No part of this manual may be copied, reproduced, translated or reduced to
any electronic medium or otherwise without the prior written consent of the copyright holder.
