VDP575MHS20FL_v3 HQPOWER 5
Channel 3 Dimmer
0 24 No function
25 255 0 – 100% dimmer
Channel 4 Colour Wheel 1
0 7 White
8 14 Blue
15 21 Pink
22 28 Cyan
29 35 Green
36 42 Yellow
43 49 Magenta
50 56 Dark cyan
Channel 4 Colour Wheel 1
57 63 Dark green
64 70 Red
71 77 Blue + pink
78 84 Pink + cyan
85 91 Cyan + green
92 98 Green + yellow
99 105 Yellow + magenta
128 191 Backwards rotation from slow to fast
192 255 Forwards rotation from slow to fast
Channel 5
Lamp on / off
Reset
0 199 No function
200 207 Lamp switches off after 3 sec
208 215 Lamp switches on after 3 sec
216 239 No function
240 247 Unit resets after 3 sec
248 255 No function
Channel 6 Colour Wheel 2
0 7 White
8 14 Red
15 21 Dark cyan
22 28 Orange
29 35 Cyan
36 42 Magenta
43 49 Yellow
50 56 65K filter
57 63 32K filter
64 70 Blue
71 77 Red + dark cyan
78 84 Dark cyan + orange
85 91 Orange + cyan
92 98 Cyan + magenta
99 105 Magenta + dark cyan
106 112 Dark cyan + Yellow
113 119 Yellow + 65K filter
120 127 65K + 32K filter
128 191 Backwards rotation from slow to fast
192 255 Forwards rotation from slow to fast
Channel 7 Static Gobo Wheel
0 7 Open
8 15 Gobo 1
16 23 Gobo 2
24 31 Gobo 3
32 39 Gobo 4
40 47 Gobo 5
48 55 Gobo 6
