PSSMV24
16.06.2010 ©Velleman nv 5
USB port
•
The USB port [4] delivers a fixed 5VDC/1A output. Simply connect a
suitable device to the port or use the included USB cable to connect a
device with a mini-USB input port.
• After use, first switch off the connected device before disconnecting the
USB cable. Always unplug the adaptor from the mains when not in use.
DC output
•
Connect the desired plug [5] to the DC output jack [3]. The plug fits
only one way, do not force! The adaptor automatically selects the
matching output voltage. This voltage is shown on the LCD.
• Make sure the device that will be powered by the adaptor is switched
off. Note: this connected device must comply with the selected
voltage, current and polarity!
• Insert the other end of the plug into the device and switch it on.
• After use, first switch off the connected device before disconnecting the
adaptor plug. Always unplug the adaptor from the mains when not in
use.
7. Maintenance
• Disconnect the adapter from the mains and wipe it with a moist, lint-
free cloth. Do not use alcohol or solvents.
• Do not submerge the adaptor in water or any other liquid.
• There are no user-serviceable parts inside the device. Refer to an
authorized dealer for service and/or spare parts.
8. Technical specifications
supply voltage 100 ~ 240VAC 47~63Hz
power 70W
efficiency >=
83%
power consumption @ 0 load <1.5W
dimensions 110 x 48 x 21mm
length USB cable 1m
plugs, voltages and dimensions see table page 2
spare plugs PLUGSPSET7
additional plugs PLUGSPSET6
weight 23g
Use this device with original accessories only. Velleman nv cannot
be held responsible in the event of damage or injury resulted from
(incorrect) use of this device. For more info concerning this product
and the latest version of this user manual, please visit our website
www.velleman.eu. The information in this manual is subject to
change without prior notice.
