311D LRR Hydraulic Excavator Specifications
Load at
Maximum Reach Load Point
Height Load Radius
Over Front Load Radius
Over Side
Reach Boom Lift Capacities
STICK – 2.8 m (9'2")
BUCKET – 0.4 m
3 (0.53 yd 3 )
UNDERCARRIAGE – Long
SHOES – 500 mm (20") triple grouser BOOM – Reach
BLADE – Up
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with SAE hydraulic excavator lift capacity rating standard J1097.
They-do-not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. Weight of all lifting accessories must be deducted from the above lifting-capacities.
1.5 m (5.0 ft) 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft)
m
ft
6.0 m kg *850 *850 6.58
20.0 ft lb *1,850 *1,850 21.35
4.5 m kg *2150 2000 *800 *800 7.44
15.0 ft lb *4,350 4,250 *1,700 *1,700 24.31
3.0 m kg *2750 *2750 *2550 1950 *800 *800 7.86
10.0 ft lb *6,000 *6,000 *5,550 4,150 *1,750 *1,750 25.75
1.5 m kg *5450 *5450 *3650 3000 2550 1850 *850 *850 7.91
5.0 ft lb *11,700 *11,700 *7,850 6,400 5,450 3,950 *1,850 *1,850 25.97
Ground kg *7050 5200 3900 2750 2450 1750 *1000 *1000 7.63
Line lb *15,150 11,150 8,350 5,950 5,250 3,750 *2,150 *2,150 25.03
–1.5 m kg *4250 *4250 *7400 5000 3750 2650 2400 1700 *1200 *1200 6.96
–5.0 ft lb *9,550 *9,550 *16,050 10,750 8,050 5,700 5,100 3,650 *2,700 *2,700 22.77
–3.0 m kg *6250 *6250 *6850 5050 3750 2650 *1750 *1750 5.74
–10.0 ft lb *13,850 *13,850 *14,700 10,800 8,050 5,700 *3,950 *3,950 18.65
–4.5 m kg *4850 *4850 *3200 *3200 4.08
–15.0 ft lb *10,100 *10,100 *7,500 *7,500 12.56
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with SAE hydraulic excavator lift capacity rating standard J1097.
They-do-not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. Weight of all lifting accessories must be deducted from the above lifting-capacities.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
STICK – 2.8 m (9'2")
BUCKET – 0.4 m
3 (0.53 yd 3 )
UNDERCARRIAGE – Long
SHOES – 600 mm (24") triple grouser BOOM – Reach
BLADE – Up
1.5 m (5.0 ft) 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft)
m
ft
6.0 m kg *850 *850 6.58
20.0 ft lb *1,850 *1,850 21.35
4.5 m kg *2150 2050 *800 *800 7.44
15.0 ft lb *4,350 4,350 *1,700 *1,700 24.31
3.0 m kg *2750 *2750 *2550 2000 *800 *800 7.86
10.0 ft lb *6,000 *6,000 *5,550 4,250 *1,750 *1,750 25.75
1.5 m kg *5450 *5450 *3650 3050 2600 1900 *850 *850 7.91
5.0 ft lb *11,700 *11,700 *7,850 6,500 5,550 4,050 *1,850 *1,850 25.97
Ground kg *7050 5300 3900 2850 2500 1800 *1000 *1000 7.63
Line lb *15,150 11,350 8,500 6,050 5,350 3,850 *2,150 *2,150 25.03
–1.5 m kg *4250 *4250 *7400 5100 3850 2700 2450 1750 *1200 *1200 6.96
–5.0 ft lb *9,550 *9,550 *16,050 10,950 8,200 5,800 5,250 3,750 *2,700 *2,700 22.77
–3.0 m kg *6250 *6250 *6850 5150 3850 2700 *1750 *1750 5.74
–10.0 ft lb *13,850 *13,850 *14,700 11,000 8,200 5,800 *3,950 *3,950 18.65
–4.5 m kg *4850 *4850 *3200 *3200 4.08
–15.0 ft lb *10,100 *10,100 *7,500 *7,500 12.56
