19 324D FM Forest Machine specifications
324D FM LL Heel Boom Under/Under Lift Capacities
CONFIGURATION – 11.6 m (38') Boom/Stick/Heel Linkage,
Heavy Counterweight
SHOES – 700 mm (28") Double Grouser
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity standard ISO 10567.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity.
Weight of all lifting accessories must be deducted from the above lifting capacities.
4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft
Load at
Load
Maximum Reach
Point Over Over Over Over Over Over Over Over Over Over Over Over m
Height Front Side Front Side Front Side Front Side Front Side Front Side ft
10.5 m kg *8850 *8850 *7850 6800 *7600 5900 8.03
35.0 ft lb *19,400 *19,400 *17,250 14,350 *17,100 13,450 25.73
9.0 m kg *7500 7000 6550 5000 6000 4550 9.37
30.0 ft lb *18,650 *18,650 *16,400 14,950 13,900 10,550 13,500 10,200 30.38
7.5 m kg *8600 *8600 *7500 7000 *6600 5100 5100 3850 10.32
25.0 ft lb *18,750 *18,750 *16,350 15,050 14,200 10,850 11,400 8,550 33.65
6.0 m kg *9050 *9050 *7700 6900 6600 5050 5050 3800 4600 3450 10.98
20.0 ft lb *19,600 *19,600 *16,700 14,800 14,150 10,800 10,750 8,050 10,150 7,600 35.93
4.5 m kg *10 500 *10 500 *9700 9600 *8000 6700 6500 4950 5000 3750 4300 3200 11.41
15.0 ft lb *23,500 *23,500 *21,000 20,650 *17,350 14,350 13,950 10,600 10,700 8,050 9,500 7,050 37.39
3.0 m kg *10 400 9100 *8300 6400 6350 4800 4950 3700 *4100 3100 11.63
10.0 ft lb *22,450 19,550 *17,900 13,750 13,600 10,250 10,600 7,900 *9,100 6,800 38.14
1.5 m kg *10 750 8600 8150 6150 6200 4650 4850 3650 *3550 3050 11.65
5.0 ft lb *23,250 18,450 17,550 13,150 13,250 9,950 10,450 7,750 *7,850 6,750 38.22
Ground kg *10 200 *10 200 *10 450 8200 7950 5900 6050 4500 *4700 3550 *2900 *2900 11.47
Line lb *24,650 *24,650 *22,550 17,600 17,050 12,700 13,000 9,700 *9,850 7,650 *6,350 *6,350 37.63
–1.5 m kg *11 050 *11 050 *9300 7950 *7200 5750 *5450 4450 *3550 3550 *2550 *2550 10..97
–5.0 ft lb *25,900 *25,900 *20,100 17,150 *15,450 12,400 *11,600 9,550 *7,100 7,650 *5,550 *5,550 35.96
–3.0 m kg *9100 *9100 *7300 *7300 *5650 *5650 *3950 *3950 *3000 *3000 9.69
–10.0 ft lb *19,600 *19,600 *15,700 *15,700 11,950 11,950 *8,100 *8,100 *6,650 *6,650 31.57
324D FM LL Heel Boom Over/Under Lift Capacities
CONFIGURATION – 12.2 m (40') Boom/Stick/Heel Linkage,
Heavy Counterweight
SHOES – 700 mm (28") Double Grouser
3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft 12.0 m/40.0 ft
Load at
Load
Maximum Reach
Point Over Over Over Over Over Over Over Over Over Over Over Over Over Over Over Over m
Height Front Side Front Side Front Side Front Side Front Side Front Side Front Side Front Side ft
10.5 m kg *7450 7150 6700 5100 8.86
35.0 ft lb *16,350 15,150 *15,150 11,600 28.51
9.0 m kg *7200 *7200 *6500 5250 5400 4100 10.09
30.0 ft lb *15,750 *15,550 *14,150 11,100 12,100 9,150 32.76
7.5 m kg *7250 *7250 *6450 5250 5150 3900 4700 3500 10.98
25.0 ft lb *15,750 *15,550 *14,000 11,250 10,950 8,300 10,400 7,800 35.81
6.0 m kg *7450 7100 *6500 5200 5150 3900 4250 3200 11.60
20.0 ft lb *16,150 15,250 *14,100 11,100 11,050 8,350 9,400 7,000 37.95
4.5 m kg *9300 *9300 *7750 6850 6600 5050 5100 3850 4000 2950 4000 2950 12.01
15.0 ft lb *20,100 *20,100 *16,850 14,700 14,200 10,800 10,900 8,250 8,800 6,550 39.34
3.0 m kg *10 050 9300 *8100 6550 6400 4850 5000 3750 4000 2950 *3850 2850 12.21
10.0 ft lb *21,700 20,000 *17,550 13,800 13,800 10,450 10,700 8,050 8,550 6,300 8,500 6,300 40.06
1.5 m kg *10 550 8700 8250 6200 6200 4650 4900 3650 *3900 2950 *3350 2850 12.23
5.0 ft lb *22,800 18,700 17,700 13,300 13,350 10,000 10,500 7,800 *7,700 6,250 *7,400 6,250 40.13
Ground kg *13 000 12 650 *10 500 8200 7950 5900 6050 4500 4800 3550 *3000 2900 *2750 *2750 12.06
Line lb *31,050 27,150 *22,700 17,600 17,050 12,700 13,000 9,650 10,300 7,650 *6,050 *6,050 39.57
–1.5 m kg *11 500 *11 500 *9650 7850 *7450 5700 *5800 4400 *4250 3500 *2300 *2300 11.63
–5.0 ft lb *26,900 26,100 *20,900 16,900 *16,100 12,250 *12,400 9,450 *8,800 7,550 *5,050 *5,050 38.13
–3.0 m kg *6350 *6350 *10 250 *10 250 *8000 7750 *6200 5600 *4600 4350 *2750 *2750 *2600 *2600 10.57
–10.0 ft lb *14,500 *14,500 *22,100 *22,100 *17,200 16,650 *13,250 12,100 *9,650 9,350 *5,750 *5,750 34.51
–4.5 m kg *5500 *5500 *4150 *4150 *3800 *3800 7.88
–15.0 ft lb *11,600 *11,600 *8,850 *8,850 24.65
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity standard ISO 10567.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity.
Weight of all lifting accessories must be deducted from the above lifting capacities.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
